Product Details:

Place of Origin: ZhangJiaGang,JiangSu,China
Brand Name: Fill Pack
Certification: CE,ISO
Model Number: TB-200S

Payment & Shipping Terms:

Minimum Order Quantity: 1 set for bottle shrink labeling machine
Price: USD$18,500- 20,500/set
Packaging Details: Sea worthy packing
Delivery Time: 5-15 days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 15 sets/Month
Get Best Price Contact Now

Detail Information

Model: TB-200S Dimension(L*W*H): 4000*850*2100 MM
Material Of Label: PVC、 PET、 OPS Automatic: Yes
Power: 4KW Main Material: Stainless Steel
Key Word: Bottle Shrink Labeling Machine Warranty: 12 Months
High Light:

industrial labeling systems

,

sticker labeling machine

Product Description

Fully automatic bottle shrink labeling machine with double head sleeve labeling system

Product Description

The bottle shrink labeling machine is made out of stainless steel SUS304. The frame is simple, beautiful, waterproof and not rust. It is easy for cleaning.The special cutting system: adopting the whist and convolute technology. The label cutting is flat, no burr.The label location set assures the sleeving veracity.Adopting model group design, module controlled; Achieve veracity and fast sleeving.With the good quality touching operation screen, achieving operation by finger, easy and shortcut.It is a high automatic packing machine. Just one person handles, easy operation.Easy to change packing material, the change over of the mould can be easily done by hand without any tools.Within the flat width limitation, can be used to package objects in different shape, no matter round or square, can be applied on glass or plastic bottles.Higher safely and stability for operation and saving time of manpower.

Fully Automatic Bottle Shrink Labeling Machine With Double Head Sleeve Labeling System 0



Working process:



Fully Automatic Bottle Shrink Labeling Machine With Double Head Sleeve Labeling System 1

Quick Detail :

Diameter of bottle body :∮28mm-∮125mm

Length of label : 30mm-250mm

Thickness of label: 0.035mm-0.045mm

Material of label:PVC, PET, OPS

Size: L4000MM*W850MM*H2000MM

Power: 4KW

The main configuration table and function of bottle shrink labeling machine:

Name

Function

Material offering group

Offer motor for label carrier

Shelf group

Install volume label device

Platform elevating group

Adjust the height of host automatically according to the bottle shapes

Brush-off group

Brushing the cutted label on the bottle

Cutter group

Cutting off the labels which are sent to Center guide pin

Cutter controlling group

Control the cutter operational site

The back drive group

Offer motor for label of center guide pin

The front drive adjusting group

Grasping the center guide pin

Frame of Electric eye group

Adjust the best cutting position of the label

Electric eye of bottle lighting detecting group

Adjust the sleeve labeling position of bottle body

Hairbrush group

Brush the label which cannot sleeve properly to the right place

Bottle positioning group

Make bottle stable, control sleeve labeling position

Center guide pin group

Make volume label distracted for transfer and cut easily

Bottle entering screw bolts

Separate bottle on equal distance in order to sleeve labeling accurately





















































Fully Automatic Bottle Shrink Labeling Machine With Double Head Sleeve Labeling System 2

1. Bottle separating mechanism

2set

7. Label carrier drive mechanism

2set

2. Bottle positioning mechanism

2set

8. Cutter mechanism

2set

3. Single material putting place

2set

9. Synchronous label brush-off mechanism

2set

4. Fiber-optical electric eye controlling

2set

10. Automatic platform elevating mechanism

2set

5. Center guide pin

2set

11. Man-machine interface of operation control panel



1set

6. Shrink oven

1set

12. Hairbrush

2set



















Delivery & Payment



Delivery:

The bottle shrink labeling machine will be made within 25-30 working days after the bottle design are confirmed;



Payment:

30% T/T deposit within five days after the contract is signed against invoice of the seller. The balance of 70% T/T before shipment.

Fully Automatic Bottle Shrink Labeling Machine With Double Head Sleeve Labeling System 3



Our services



1.Installation & adjustment

After the equipment are arrived at the customer’s site, the customer is responsible for unpacking and arranging the equipment according to the placement drawing; and does under our install-adjust technicians’ guidance. Costs of the staff are decided at last.



2. Training

  • We are responsible for offering the technical training to user. The training content includes the structure and maintenance of the equipment, control and operation of the equipment. Through training, users' technical staff can grasp and the skill of operation and maintenance proficiently, and deal with the general troubles in time. We will appoint qualified technical staff for the guidance.
  • The buyer can send staff to our company for learning.

3. Quality assurance

  • We guarantee the goods offered are brand-new, not used, with latest design and suitable material made, and we guarantee the specification of the equipment is consonance with the contract.
  • We guarantee the line achieve product technical performance indicators within 5 days after feeding operation through the correct guidance of the installation and commissioning.
  • We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc. that all belong to our responsibility.
  • The warranty period is 12 months after acceptance check of the production line. If there is any different between the furnished equipment in the customer’s factory and the equipment concerned in the contract, the users have the right to pass the inspection book to the legal department to claim for compensation to our company within goods warranty period.

Fully Automatic Bottle Shrink Labeling Machine With Double Head Sleeve Labeling System 4
