SUS304 Injector Ln2  Liquid Nitrogen Doser With Installation Rack

SUS304 Injector Ln2 Liquid Nitrogen Doser With Installation Rack

Product Details:

Place of Origin: China
Brand Name: FILLPACK
Certification: CE
Model Number: model-300

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 11,000 USD
Packaging Details: Carton package
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, , MoneyGram
Supply Ability: 1 set per week
Get Best Price Contact Now

Detail Information

Type: Filling Machine Application: Food, Beverage, Commodity
Driven Type:: Electric Machinery Capacity:: 6000BPH
Material:: 304 Stainless Steel Liquid Nitrogen:: 3-22psi (0.2-1.5bar)
Voltage: 110-240VAC; 50 / 60HZ, 100W Weight: 15KG
Core Components:: Other, PLC Gas Nitrogen:: 60-100 Psi (4.1-6.9 Bar)
High Light:

ln2 liquid nitrogen doser

,

SUS304 liquid nitrogen doser

,

Injector ln2 doser

Product Description

Liquid Nitrogen doser / Dosing / Injector / injection machine / equipment / unit with installation rack

SUS304 Injector Ln2  Liquid Nitrogen Doser With Installation Rack 0

Characters:
1.Compact model-easy to install in a small space.
2.Sensor monitoring system to make sure dosing correctness. 3.Nitrogen Injection
Accurate - Provides stable and accurate nitrogen injection+/-0.2%.
4.Individual dosing or continuous dosing - Changing the speed of the fill mode can be set by the user.
5.Speed automatic dosing compensation function-the system calculates the required liquid
nitrogen injection volume according to the container speed.
6.Vacuum Adiabatic Technology - Improving Liquid Nitrogen Use Efficiency.
7.Soft dosing compatible - suitable for liquid, powder, and granular products,and it is a successfully verified dosing
technology.
8.Nitrogen positive pressure protection - nozzle using dry nitrogen positive pressure protection, to prevent the
external air into the nozzle caused by internal frost, ice blocking
9.gas-liquid separation function to get higher N2 purity
10.Remote nitrogen injection function - remote access and control, improve efficiency and reduce downtime. Could be optional.



Insulation hose technical index: 1.design temperature:-270℃ 2.Adiabatic form: high vacuum multi-layer multi-screen 3.Average cold loss of pipeline: ≤0.5w/m 4.Working pressure: according to drawings 5.Pipeline vacuum leakage rate: ≤2×10-10paL/S 6.Pipeline design life: 30 years 7.Interlayer pressure: ≤2×104Torr 8.Inner tube strength test: 1.15 times the design pressure 9.Design pressure: divided by grade



material
304 stainless steel
Plus head size
270mm × 57mm
Length of arm
380mm
nozzle
0.040 ", 0050", 0.060 "
Supply facility
Liquid nitrogen: 3-22psi (0.2-1.5bar)
Gas nitrogen: 60-100 psi (4.1-6.9 bar)
Power: 110-240VAC; 50 / 60HZ, 100W
Liquid nitrogen evaporation loss
0.04gai (0.2 liter) per hour
Raise time
15to1000 milliseconds(1 millisecond interval)
Filling volume
0.01to14 g / time
Individual filling the highest speed
300
Continuous filling the highest speed
1500
Accuracy of fluence
± 5% dosing weight
