High Definition 200DPI Automatic Online Industrial Inkjet Date Coder
Product Details:
| Place of Origin: | ZhangJiaGang,JiangSu,China |
| Brand Name: | Fill Pack |
| Certification: | CE,ISO |
| Model Number: | OH-338 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD740/set |
| Packaging Details: | carton packing |
| Delivery Time: | 5 - 7 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 15 sets/month |
|
Detail Information |
|||
| Ink Color:: | Black, Red, White | Dimension: | 370*270*380mm |
|---|---|---|---|
| Inkjet Printing Precision:: | 200 DPI | Weight: | 6KG |
| Power Supply Parameters:: | Power Supply Parameters: | External Interface:: | USB, Synchronizer, Photoelectric Sensor, Data Line |
| High Light: | 200DPI industrial inkjet coder,high definition industrial inkjet coder,200DPI inkjet date coder |
||
Product Description
automatic online inkjet code printer for time / date printing line
Features
1)It has a Built-in pinyin input method of national Primary and Second Chinese character(more than 6000 Chinese characters).
2)The host has four font (Song type face, Hollow font, Bold font, Bitmap font).The four font can be mixed in arrangement. If you need other font, you can also transmit through computer.
3)It can jet one to fifteen lines of English Numbers, or one to eight lines of Chinese characters, and the size of the word can be adjusted. This system is dual-purpose.
4)The editing interface can switch at any time to either English or Chinese.
5)It has indicator light for Photoelectric sensor, synchronizer and inkjet printing to show whether they are working normally.
6)Flash spray. Nozzle will not be blocked even standby for a long time.
7)It can be entered graphic of arbitrary length, instead of fixed graphic .
8)The machine can be directly edited printing information without computer. It has humanized design and fool type operation.
9)It has USB ports, which allows to access designed trademark from computer.
10)The two circuits for feeding ink are merged, which saves installation space of the equipment.
Technical Specification
1)Inkjet printing precision: 200 DPI
2)Inkjet print fonts: high-definition inkjet print fonts ( print form)
3)Character: national Primary and Second Chinese character(more than 6000 Chinese characters), seven font (Song typeface,Regular script, Hollow, Bold, Clouds, New Song typeface, Bitmap font) to choose from, pinyin input method.
4)Inkjet print graphics: all sorts of trademark design can be printed, graphic transmission is not affected by length-to-width ratio and length.
5) The number of lines: one to fifteen lines of English Numbers or one to eight lines of Chinese characters can be printed, and the size of the word can be adjusted. This system is dual-purpose.
6) Character height: 1 mm ~ 12.7 mm high word font can be printed
7) Inkjet print distance: nozzle to printing objects 5-10 mm
8) Automatic inkjet printing: date, time, batch number, class and serial number, etc
9) Storage information: 100 messages, 100 graphics can be stored
10) Message length: each message can be up to 200 characters
11) Serial number: Number of Bits 1-8 bits variable sequence number
12) Inkjet printing speed: up to 75 m/min, and inkjet printing speed does not change due to the increase of the number of lines(Capacity reach max around 10000 bottles per hour)
13) Ink color: black, red, white
14) Inkjet print direction: nozzle is rotatable, adjusted to forward, backward and straight down.The program is set to adjust upside down and turn around.
15) Material for inkjet printing: the surface of metal, plastic, wood, aluminum foil, cartons and building materials and so on.
16) Application: such as mobile phone screen, Beverages cap , food packaging bags, medicine boxes, plastics-steel doors and windows, aluminum alloy, batteries, plastic pipe, steel plate, circuit boards, chip, woven bags, eggs, brake pad, phone housings, cartons, motors, transformers, inside dishes of water meter, gypsum board, PCB circuit board, outer packing of explosive, etc.
17) Ink used: environmental protected quickly dry printing ink or oil-based ink, no need to use external gas or diluent
18) External interface: USB, synchronizer, photoelectric sensor, data line
19) The machine size: 34.7 x22x 10 cm
20) Power supply parameters: AC 220 v
21) System power consumption: the average power consumption is less than 100 w
22) Application Environment: temperature (0 ℃ to 40 ℃); humidity(40% to 70%)
23) Status display: spray printing, synchronizer and photoelectric have light display when they are normally working The external packing size of ink cartridge is 13x4x4cm, and the expiration date of the ink cartridge is 9 months. It is recommended to use it within 6 months after opening. No quantity for one cantainer, Packing according to the required quantity.
