PLC Control 3 In 1 Water Filling Machine SUS304 With Screw Cap

PLC Control 3 In 1 Water Filling Machine SUS304 With Screw Cap

Product Details:

Place of Origin: Zhangjiagang, China
Brand Name: FillPack
Certification: CE / ISO9001 - 2008
Model Number: CGF32-32-10
Condition: New
Application: PET bottle water
Automation: Automatic
Suitable Bottle Size: 0.3-2L PET Bottle
Fuction: washing filling capping monoblock
Capacity: 12000-15000BPH
Warranty: 1 Year for Spare Parts
Service: Technician avaliable overseas

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 12000-30000USD
Packaging Details: Wooden Case Package
Delivery Time: 30 Working Days After Deposit
Payment Terms: TT & L/C
Supply Ability: 20 Sets Per Months
Get Best Price Contact Now

Detail Information

High Light:

water production line

,

water filler machine

Product Description

PLC Control 3 In 1 Water Filling Machine SUS304 With Screw Cap





Quick Detail:



Machine: Small Bottle Automatic Water Filling Machine Monoblock

Applicative Bottle: PET bottle

Applicative cap: Screw cap

Applicative volume: 0.3-2L

Applicative liquid: non gas water
Production Capacity: 12000-15000bph
Machine construction: washing filling capping 3 in 1

Advantage: USA - Germany technology





Description:



1. The 3 In 1 Water Filling Machine is full automatic machine with PLC control, client only need to set datas in touch screen for speed regulation, and choose semi-auto or automatic working status. There is automatic fault advice and alarm when there is mistake happen in the machine. It is easier for client to find machine problem by themselves during daily use.

2. The 3 In 1 Water Filling Machine is composed by rotary washer, normal pressure filler, screw type capper and conveying system. More heads, higher capacity.

3. The 3 In 1 Water Filling Machine is using rotary gravity filling technology, it makes sure filling is fast and stable, filling lever is same bettween different bottles. Also it is very easy for client themselves to adjust water lever as they want.

4. The speed of 3 In 1 Water Filling Machine is higher than traditional linear type machine.

5. It is used for filling all kinds of non gas water, such as still water, mineral water, flavored water, spring water, oxygen water, hydrogen water.

6. The usual production capacity is in 1000-24000bph, 0.2-2L PET bottle is available.





Specifications:



Model CGF8-8-3 CGF12-12-4 CGF18-18-6 CGF24-24-8 CGF32-32-10
Washing Head No 8 12 18 24 32
Filling Head No 8 12 18 24 32
Capping Head No 3 4 6 8 10

Rated

Capacity

(500ml)

3000BPH 4000BPH 7000-8000BPH 10000-15000BPH 15000-20000BPH
Overall Size

1900*1420*

2000mm

2200*1600*

2300mm

2450*1900*

2300mm

2750*1180*

2400mm

4000*2300*

2300mm

Weight 1.5T 2.2T 3.0T 4.0T 8.0T

Power

(KW)

3.0kw 3.5kw 4.0kw 4.8kw 7.6kw
Rated Voltage Customized Customized Customized Customized

Customized





Competitive Advantage:



1. One year warranty for the whole system

2. Free equipment installation and debugging

3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

4. Every 3 years, we can help to overhaul the machine free (Labor)

5. We can provide internship service and help you train the operator and mechanic

6. Free production technology and process configuration

7. We can help you to design the production line, workshop and provide turn-key project
