Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine

Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine

    • Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine
    • Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine
    • Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine
    • Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine
  • Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine

    Product Details:

    Place of Origin: ZhangJiaGang City, JiangSu Province, China
    Brand Name: FillPack
    Certification: CE, ISO
    Model Number: CG-1
    Application: Food and beverage production line
    Applicable can: New empty can
    Washing material: Pure water
    Power: 0.75 KW
    Material: SUS304
    Driven Type: Electric
    Condition State: New
    Service: Engineer available to oversea service
    Guarantee Time: 1 Year

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set/pcs
    Price: Negotiation
    Packaging Details: Blanket cloth or wooden case pacakge
    Delivery Time: 10-15 days
    Payment Terms: 30% T/T deposit, 70% before shipment
    Supply Ability: 50 sets/month
    Contact Now
    Detailed Product Description

    Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine





    Quick Detail:



    1. For washing new empty tin can, not avaliable to aluminum can and PET can

    2. Capacity: 2000 Cans / Hour

    3. Main material: SUS304

    4. Applicable can diamater: 40-100mm, above 100mm should be customised.

    5. Adopt the magnet functio with tin can, use the water pump for water rinsing.





    Description:



    This tin can washer is mainly used for continuous washing for empty tin cans of similar size and shape. It is designed as requirement of filled drink in metal can. It is used to continuously washing three pieces of pop can; The machine is full automatic. It adopts the high quality of stainless steel 304 material, meets the requirements of food grade.



    The automatic tin can filling line is mainly used to filling non-carbonated drink, like juice, milk, wine and so on.

    It main contains the automatic can washer, can filler, can sealer and chain conveyor and motor, automatic with speed adjustable.





    Working process:



    Before operate the machine, please get through the power and water source. Turn on the switch of machine, then operator put the cans at the beginning of the conveyor by manual, the cans will go with the conveying force of motor; With the magnetic effect, tin cans are running down- opening to bottom along with the conveyor, the continuous water will spread into tin. And then the tins will be dripped drying when reverse hanging. The washing machine has characteristic on logically design, easy operation and higher production.





    Components:



    Machine frame, one motor, one set conveyor track and magnetic device, two set belt pulley and one set water spraying device.





    Characters:



    1, Can inlet side wide range design can allow as many cans loading each time and increase working  efficiency;

    2, USA tech high efficiency water spray ball can spray water all directions inside cans to increase water using efficiency;

    3, Plastic glass cover will stop water to go outside and easy to open for Maintenance;

    4, It is easy to design can inlet and outlet direction by design can rail direction;

    5, It can connect with filling machine after;

    6, Speed easy adjustable by press buttons;





    Applications:



    1. This tin can washer is mainly used for continuous  water washing for empty tin cans of similar size and shape, then next used for filling the non-carbonated drink like juice, milk, wine and so on to tin cans, then seal the cans for market selling.

    2. This tin can washer is suitable for new tin can, form diamater 40-100mm, one machine is avaliable to same can diameter but different can height, don't need to set with extra can change parts, easy to use.





    Specifications:



    Model CG-1
    Capacity 1000-2000 Cans/H
    Material SUS304
    Applicable tin can diameter 40-100mm
    Applicable tin can height 50-300mm
    Speed of belt: Fixed
    Power 0.75KW
    Water pressure 0.15Mpa
    Dimension L1900*W600*H1200mm
    Weight 350kg



    Industrial Can Filling Line , Juice Tin Can Washer Rinser Machine

    please kindly click the play button to watch the video
