5L Pure Water Bottle Filling Machine 3 In 1 Liquid Filler Equipment
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001 - 2008 |
| Model Number: | CGF |
| Condition: | New |
|---|---|
| Application: | PET bottle water |
| Automation: | Automatic |
| Suitable Bottle Size: | 5L PET Bottle |
| Fuction: | linear washing filling capping line |
| Capacity: | 2000BPH |
| Warranty: | 1 Year for Spare Parts |
| Service: | Technician avaliable overseas |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | Sea worthy Package |
| Delivery Time: | 20 Working Days After Deposit |
| Payment Terms: | TT & L/C |
| Supply Ability: | 50 Sets Per Months |
|
Detail Information |
|||
| High Light: | aseptic filling line,water bottling equipment |
||
|---|---|---|---|
Product Description
5L Pure Water Bottle Filling Machine 3 In 1 Liquid Filler Equipment
Quick Detail:
Machine structure: 3 in 1 filling machine
Filling type: Normal pressure filling
Bottle type: 5L plastic bottle
Filling material: Pure water
Operation manner: Auto / Manual
Description:
The bottle filling machine is monoblock filling machine which integrate washing, filling and capping machine in one unit. It is used to fill pure water, mineral water, and other non-carbonated water into plastics bottles. The bottles can be various, but the bottle mouth must be the same so that they can be used in one machine.
Specifications:
| Model | CGF8-8-3 | CGF12-12-4 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 |
| Washing Head No | 8 | 12 | 18 | 24 | 32 |
| Filling Head No | 8 | 12 | 18 | 24 | 32 |
| Capping Head No | 3 | 4 | 6 | 8 | 10 |
|
Rated Capacity (500ml) |
3000BPH | 4000BPH | 5000-7000BPH | 8000-12000BPH | 12000-15000BPH |
| Overall Size |
1900*1420* 2000mm |
2200*1600* 2300mm |
2450*1900* 2300mm |
2750*1180* 2400mm |
4000*2300* 2300mm |
| Weight | 1.5T | 2.2T | 3.0T | 4.0T | 8.0T |
|
Power (KW) |
3.0kw | 3.5kw | 4.0kw | 4.8kw | 7.6kw |
| Rated Voltage | Customized | Customized | Customized | Customized | Customized |
Competitive Advantage:
1. One year warranty for the whole system
2. Free equipment installation and debugging
3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
4. Every 3 years, we can help to overhaul the machine free (Labor)
5. We can provide internship service and help you train the operator and mechanic
6. Free production technology and process configuration
7. We can help you to design the production line, workshop and provide turn-key project
Market Distribution:
| Market | Revenue(Previous Year) | Total Revenue (%) |
| Africa | confidential | 40% |
| Middle east | confidential | 15% |
| America | confidential | 5% |
| Euro | confidential | 4% |
| Middle Aisa | confidential | 3% |
| South-east Asia | confidential | 3% |
| Domestic | confidential | 30% |
