Single Head Servo Motor Automatic Soda Can Sealer Machine
|Place of Origin:||Zhangjiagang, China|
|Brand Name:||FILL PACK|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 unit|
|Packaging Details:||Sea worthy package|
|Delivery Time:||30 Working Days After Deposit|
|Supply Ability:||15 units Per Months|
|Applicable Cans:||Tin Can- Aluminum Can- Plastic Can -Paper Can||Applicable Lids:||Round 200-209|
|Weight:||500KG||Sealing Head:||Double Head|
|Number Of Seaming Rollers:||4 (2 First Operation, 2 Second Operation)|
servo soda can sealer machine,
Single head automatic can sealer,
servo motor automatic can sealer
Single head servo motor Can sealing machine / Can seamer / sealer device / equipment / unit
1.The servo control of the whole machine makes the operation of the equipment more safe, stable and intelligent. The turntable can be started only when there is a tank; the speed of the turntable can be adjusted independently; when the can is stuck, the turntable will stop automatically, and the fault can be removed and run again after one key reset; when there is foreign matter stuck in the turntable, the rotary table will automatically stop running, so as to prevent the equipment damage and safety accidents caused by human error operation.
2. Two sealing heads work at the same time, the sealing speed is more efficient. There are four sealing wheels in each sealing mouth to ensure high sealing degree.
3. During the sealing process, the tank body does not rotate, which is more safe, especially suitable for fragile and liquid products. The sealing wheels are in 2 step sealing model to make sure the the can edge and lid edge close tightly. Then the sealed can will be suitable for all kinds of liquid, no leakage.
|Name of machine||Country/Region||Brand|
|Frame, guardrail material||China||SUS304|
|Motor frequency converter||Taiwan||Delta|
1, Ingenious lid loading device to make sure no can, no lid loading, no sealing;
2, Energy saving model, one motor can process all actions;
3, Full sealing effect make sure to be suitable for all cans including liquid packing can;
4, The machine suitable for all kinds of cans with same diameter, height can be adjusted easily;
5, Compact construction, only need small space to use the machine;
6, Delivered with whole machine, no need commissioning again after delivery;
Applicable cans: tin can- Aluminum can- Plastic can -Paper can
Applicable lids: round 200-209, machine need to be customized for lid 211-603
Number of sealing head: 2
Number of seaming rollers: 4 (2 first operation, 2 second operation)
Capacity: 4500BPH for cans which diameter≤65mm(adjustable)
Total power: 2.1KW
Dimensions: L 2000* W 1100* H1650mm
The machines will be made within 20 working days after the bottle design are confirmed;
30％ T/T deposit within five days after the contract is signed against invoice of the seller.
The balance of 70％ T/T before shipment;
We response for one year warranty for the machine, however, it without any human conduct. And provide one-year free spare part for client. And send engineer to client’s company with client’s provision for flight charge and accommodation. Help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.
