PE Film Heat Tunnel Bottle Wrapping Packing Machine 5pcs/Min

PE Film Heat Tunnel Bottle Wrapping Packing Machine 5pcs/Min

Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FillPack
Certification: CE. ISO9001
Model Number: BZJ-5538

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: USD$3000/set
Packaging Details: Sea worthy package
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 25 sets/month
Get Best Price Contact Now

Detail Information

Packaging Materials: PE Film Automatic Grade:: Semi-automatic
Packing Speed:: 0-5pcs / Min Shrinkage Power:: 20Kw
High Light:

heat tunnel bottle wrapping machine


5pcs/Min Bottle Packing Machine


5pcs/Min bottle wrapping machine

Product Description

Semi- Automatic water pet bottle PE film heat tunnel shrink packing machine shrink wrapping machine

Working principle:
Shrink packing is one of the developed packing method in current market, it uses shrink film wrapping outside the products, after heating, the film will shrink, it will show the goods better and it will improve sales of the goods, increase value of the goods. At the meantime, the goods after packing will be prevented from moisture and pollution, it will buffer the outside conflict, especially when the goods is easy to break, it will stop the scatter. Workers put bottles as arranged group requirement, we will give group arrangement helping device for easy arrangement, after bottle arrangement, worker press start to indicated the wrapping device to wrap PE film on the group of bottles, then film cutting, group transmission and final shrinkage will be done by machine automatically;


PE Film wrapping -cutting unit


Technical data:

● Max wrapping size: Length:350mm,width:400mm

● Max sealing length: 550mm

● Working air pressure requirement: 0.1m³/min

● Power source: AC220-240V 50/60HZ

● Power: 40W

● Dimension: 1100*1100*2050mm

● Weight: 230kg


Pack shrink tunnel unit

Technical data
Tunnel inner size
Shrinkage Power source
AC 380 V 3PH
Shrinkage Power
380V 3PH 0.75KW
Conveyor motor
AC 220V /200W
Conveyor speed
Max loading
