Soft Drink Aluminum Can Filler Machine , Commercial Can Sealing Equipment
Product Details:
| Place of Origin: | ZhangJiaGang City, JiangSu Province, China |
| Brand Name: | FillPack |
| Certification: | CE,ISO |
| Model Number: | FXZ-1 |
| Application: | Food and beverage production line |
|---|---|
| Applicable can: | Aluminum can or PET can with carbonated drink |
| Washing material: | 1 head |
| Power: | 0.75 KW |
| Material: | SUS304 |
| Driven Type: | Electric |
| Condition State: | New |
| Service: | Engineer available to oversea service |
| Guarantee Time: | 1 Year |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set/pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Blanket cloth or wooden case pacakge |
| Delivery Time: | 15-20 days |
| Payment Terms: | 30% T/T deposit, 70% before shipment |
| Supply Ability: | 50 sets/month |
|
Detail Information |
|||
| Highlight: | bottling filling machine,water bottling plant |
||
|---|---|---|---|
Product Description
Soft Drink Aluminum Can Filler Machine , Commercial Can Sealing Equipment
Quick Detail:
1. Capacity: 1000-2000 Cans/Hour
2. For sealing aluminum can or PET can containing liquid beverage or food or solid
3. Automatic with speed adjustable
4. Main material: SUS304
5. With automatic cap loader and 1 sealing head
6. One machine is avaliable to same can diamater with different can height
Description:
The soft drink can filling line - aluminum can sealer is with 1 sealing head, suitable for sealing various cans, such as tin can, aluminum can, PET can. It is perfect in performance, reliable in operation and easy in maintenance. The machine is full automatic and the speed can be adjustable. It adopts the high quality of stainless steel 304 material, meets the requirements of food grade. So it is widely used in automatic packing lines for various kinds of milk, juice, wine, drink, pharmacy chemicals, reagent, pesticide and so on. It is one of the most ideal automatic sealing equipment.
It has the function that when with the can, the cover will fall off, without the can, the cover will not fall off. Also it is set with the automatic machine stop device for the faults of with can without the cover, without the can and cover, can stuck in feeding and coming out.
Working process:
Cans full filled coming through the chain conveyor to the can sealer, when the electromagnetic induction sensor inducts the can, it will indicate the cover loader to fall off the cover to the can, through the cam and sealing wheel, one can will be finished and coming out through the chain conveyor.
Components:
Machine transmission system: motor, main wheel, worm fear, limited cam
Cover sealing system: sealing wheel, cover pressing head, compression springs.
Machine frame, electric control system, one speed regulator motor, operation board.
Specifications:
| Model | FXZ-1 |
| Production Capacity | 1000-2000 Cans/H |
| Capping head | 1 head |
| Material | SUS304 |
| Diameter of can | 35-150 mm |
| Height of can | 50-180mm |
| Power | 0.75kw |
| Overall Dimensions | 1050×850×1800mm |
| Weight | 400kg |
For more details, please feel free to contact me, hilary.
please kindly click the play button to watch the video
