Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Purification Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Purification Equipment / Plant / Machine / System

Product Details:

Place of Origin: ZhangJiaGang City, JiangSu Province, China
Brand Name: FillPack
Certification: CE,ISO
Model Number: Filter-FRP

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Blanket cloth or wooden case pacakge
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 50 sets/month
Get Best Price Contact Now

Detail Information

Materials: Fiber Reinforced Plastic (FRP) Color Available: White, Blue Or Customized
Usage: Pure Water Process Testing Pressure:: 0.9Mpa (150psi)
High Light:

water ro system

,

ro water purifier machine

Product Description



Description of our FRP Mechanical pre-filters of water treatment system



Application:
pre RO, Ion Exchange, Water softener, waster filtration, House hold water filtration, Food and beverage, water storage

Opening:
2.5”~4” UN threads ABS opening;
6” Flange FRP;
other customized manway and side flange

Advantage:
Good corrosion resistance
High mechanical strength at low specific gravity
Good resistance to weathering
Light weight
Good insulating qualities
Provide less maintenance & repairs down time
Easy installation



Mineral / pure drinking water ion exchanger / precision / cartridge purification equipment / plant / machine / system

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Purification Equipment / Plant / Machine / System 0

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Purification Equipment / Plant / Machine / System 1

Structure Instuctions:

1, Backwashing:
When the filter runs to a certain time, there are more impurities in the tank. The filter needs to be backwashed. When backwashing, the exhaust valve 5, the upper exhaust valve 7 and the lower inlet valve 8 are opened, the upper inlet valve 6 and the outlet valve 2 are closed, and the water flows out from the lower outlet 3. Backwashing flow generally controls the filter material not to be washed out, generally about three times the operation time. Backwashing ends when the transparency of the incoming and outgoing water is similar.
2, Positive washing:
After backwashing, close the lower inlet valve 8, the upper exhaust valve 7 and the outlet valve 2, open the upper inlet valve 6 and the lower exhaust valve 9, and start the positive washing of the filter material. The positive washing flow rate is the running flow rate, and the time is usually 10-20 minutes. When the effluent is clear and transparent, the equipment can continue to be put into operation.



Parameters of our FRP Mechanical pre-filters:

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Purification Equipment / Plant / Machine / System 2

The FRP Mechanical pre-filters are matched with water treatment:

Model Size Used for Water treatment machine
818 200X450 0-100LPH
835 200X 875 100-250LPH
844 200X1100 100-250LPH
942 200X1050 250-500LPH
1035 250X875 250-500LPH
1054 250X 1350 250-500LPH
1252 300X 1300 500-1000LPH
1354 325X 1350 1000-1500LPH
1465 350X 1625 1000-1500LPH
1665 400X1625 1500-2000LPH
1865 450x1625 2000-2500LPH
