Digital Gear Pump Liquid Oil Filler Machine Desktop 4 Head High Precision
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FILLPACK |
| Certification: | CE/ISO9001 |
| Model Number: | 1 head/ 2 heads/4 heads |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 1750USD-6650USD |
| Delivery Time: | 7 Working Days After Deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 20 Sets Per Months |
|
Detail Information |
|||
| Filling Speed: | Determined By The Filling Volume And The Number Of Heads | Power: | 400W-1600W |
|---|---|---|---|
| Volume: | 10ml-11000ml | Filling Accuracy: | 0.5-1% |
| Total Weight: | 18-72KG | Size: | 460*480*310mm |
| Driven Type: | Electric | Filling Head: | 1/2/4 Heads |
| Filling Material: | Viscous Liquid | ||
| Highlight: | 1600W Liquid Oil Filler,Desktop 4 Head High Precision Pump,Digital Gear Pump Liquid Oil Filler |
||
Product Description
Desktop 1/2/4 Head High Precision Pump Digital Filler Gear Pump Liquid Filler Oil Filling Machine
Instructions:
1. Using the principle of gear pump, the microcomputer controls the measurement and speed to fill the liquid into the container, the measurement is accurate, and it is suitable for various liquids.
2. The filling volume, speed and the time between of filling can be designed.
3. Each filling can be fast first and slow later, bubble can be eliminated.
4. The operation panel is sealed and waterproof, and the parameters can be set at the touch of a button. The LCD screen can monitor the production parameters and running status in real time.
5. It can store up to 20 sets of product data, which is convenient for customers to adjust filling specifications and output at any time.
6. The pump body is exquisitely designed without tools, easy to disassemble and easy to clean.
7. It can be used in conjunction with conveyor belts, and a maximum of 4 conveyor belts can be installed.
Parameters:
| Model | 1 head | 2 heads | 4 heads |
| Power | 400W | 800W | 1600W |
| Volume | 10ml-11000ml | 10ml-11000ml | 10ml-11000ml |
| Filling speed |
100 ml 24B/min 300 ml 16B/min 1000 ml 10B/min |
100 ml 48B/min 300 ml 32B/min 1000 ml 20B/min |
100 ml 96B/min 300 ml 64B/min 1000 ml 40B/min |
| Filling accuracy | 0.5-1% | 0.5-1% | 0.5-1% |
| Total Weight | 18kg | 36kg | 72kg |
Applicable to the food,cosmetic,pharmaceutical,chemical and other industrial of liquid and semi-liquid filling.Especially suitable for alcohol,method,perfume,nail polish remover,nail polish,glycerin,acetone,Corrosive materials such as glutaraldehyde,disinfectant.
