40 Heads Soft Drink Filling Machine , Monoblock Filling Machine

40 Heads Soft Drink Filling Machine , Monoblock Filling Machine

    • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
    • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
    • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
    • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
    • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
  • 40 Heads Soft Drink Filling Machine , Monoblock Filling Machine

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: DCGF32-32-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: TT & L/C
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Capacity: 12000-15000BPH Electrical Brand: Mitsubishi, OMRON, SIEMENS
    Control Manner: PCL Control Machine Structure: Monoblock Filling Machine
    Filling Type: Balanced Pressure Filling Machine Warranty: 1 Year

    40 Heads Soft Drink Filling Machine , Monoblock Filling Machine





    Quick Detail:



    Name: 40 Heads 12000-15000 Bottles / Hour Soft Drink Filing Line For PET Bottle

    Material: Food stage stainless steel
    Control: PLC & touch screen control
    Capacity: 8000-10000bph
    Suitable Bottle: PET bottle
    Bottle Volume: 0.3-2L
    Dimension: By order
    Function: Washing filling capping 3 in 1
    Technology: Germany & Japan
    After-sales service provided: Engineers available to service machinery overseas .





    Description:



    1. DCGF 40-40-12 is used for filling carbonated soft drink, soda water, lemon and other carbonated

    beverage

    2. The capacity of filling machine (DCGF 40-40-12) is 12000-15000b/h, we can also do other capacity

    as clients' demand.

    3. This model carbonated drink filling machine is suitable for PET bottle, screw cap. Carbonated drink

    filling machine for glass bottle, aluminum cap is also avaiable.



    4. Material for filling machine is SUS 304

    5. We can provide OEM & ODM service

    6. The glass bottle carbonated drink filling machine is controlled by PLC with touch-screen as the

    human-machine interface.

    7. The production capacity can be displayed digitally and can be adjusted conveniently.

    8. There are three functions integrated in one machine, they are washing, filling, capping, so it is

    convenient for the carbonated drink like coca-cola and sprite or soda water filling.





    Specifications:



    Model DCGF12-12-4 DCGF 18-18-6 DCGF 24-24-8 DCGF G32-32-10
    Production B/H(600ml) 3000-4000 4000-6000 6000-8000 8000-12000
    Bottle standard Neck:φ50-100mmHeight150-320mm
    Water pressure of washing bottle 0.18-0.25Mpa
    Water consumption for washing bottle (kg/h) 1300 2000 3000 4000
    Spraying position 4 7 10 14
    Dripping bottle position 3 5 8 10
    Filing precision +5MM
    Gas source pressure 0.4Mpa
    Gas consumption(m³/min) 0.3 0.4 0.5 0.7
    Total power(KW) 4.2 4.5 5 6.2
    Total weight (T) 2 2.5 3 4
    Dimension (L*W*H)mm 2100*1600*2100 2500*1750*2100 2700*2100*2100 3500*2100*2100















    Competitive Advantage:



    1. One year warranty for the whole system

    2. Free equipment installation and debugging

    3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

    4. Every 3 years, we can help to overhaul the machine free (Labor)

    5. We can provide internship service and help you train the operator and mechanic

    6. Free production technology and process configuration

    7. We can help you to design the production line, workshop and provide turn-key project





    Market Distribution:



    Market Revenue(Previous Year) Total Revenue (%)
    Africa confidential 40%
    Middle east confidential 15%
    America confidential 5%
    Euro confidential 4%
    Middle Aisa confidential 3%
    South-east Asia confidential 3%
    Domestic confidential 30%



    40 Heads Soft Drink Filling Machine , Monoblock Filling Machine
