3000BPH Soy Sauce Bottle Filling Machine With Heat Preservation Balance Tank

3000BPH Soy Sauce Bottle Filling Machine With Heat Preservation Balance Tank

Product Details:

Place of Origin: Zhangjiagang, China
Brand Name: FillPack
Certification: CE / ISO9001 - 2008
Model Number: WFGF12-4

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: wooden case package
Delivery Time: 25 Working Days After Deposit
Payment Terms: L/C, T/T,
Supply Ability: 20Sets Per Months
Get Best Price Contact Now

Detail Information

Production Capacity: 3000BPH Filling Pressure: Tiny Negative Pressure
Capping Type: Vacuum Capping Suitable Bottle: PET Bottle
Materail: SUS316L Motor Driving: Electric
High Light:

aseptic filling line

,

water bottling equipment

Product Description

3000BPH Soy Sauce Bottle Filling Machine With Heat Preservation Balance Tank

3000BPH Soy Sauce Bottle Filling Machine With Heat Preservation Balance Tank





Introduction



      WFGF12-4  2in1 soy sauce machineintegrating with filling and capping, it realizes full automation in the whole process, suitable for PET bottle with flip top cap.

     The bottle types applicable for various parts are easily, conveniently and rapidly adjustable. Soy sauce machine adopts tiny negative pressure filling way. Compared with the machines of the same specification, the productivity and benefit of this machine is more larger.

     Soy sauce machine adopts advanced MITSUBISHI PLC to control the automatic running of the machine. The input bottle chain adopts speed control by frequency variation; the output bottle chain adopts adjustable speed way, which combines with the transducer of the host machine making the output bottle running more stable and reliable.

     The photoelectrical inspection of the running condition of various parts makes a higher automation and convenient operation.





Machine Specifications



Function Filling and capping 2 in 1
Filling material soy sauce, vinegar, alcohol, wine,etc.
Filling speed 3000Bottles per hour
Capping type Vacuum capping
Filling heads  12 pcs
Capping heads 4 pcs





Technical parameter



Model WFGF12-4
Production capacity 3000BPH
Dimension 1910*1590*2120mm
Power 6.21Kw
Weight 2600Kg





Bottle flow



    The bottles sent by enter bottle conveyor belt will divided into a fixed interval of one-way,and the bottle inverted by enter bottle clamp, then the bottles can be sent to filling machine’s

enter bottle star-wheel. The bottle by lift-up motion is fixed on the bottom of filling parts.

After filling, the bottle pallet lowered, centering guide rod upward , the bottles are sent to conveyor

star-wheel, then to capping star-wheel.

    After capping process, the bottle will be sent to out bottle conveyor belt by out bottle star wheel.





Electrical apparatus:



PLC/ transducer/ touch screen Mitsubishi
Contactor/ air switch/ stabilized voltage supply Schneider
Photoelectricity/ proximity switch Autonics
Cylinder Airtack
Motor AB motor



3000BPH Soy Sauce Bottle Filling Machine With Heat Preservation Balance Tank 0
