0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control

0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control

    • 0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control
    • 0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control
    • 0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control
    • 0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control
  • 0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control

    Product Details:

    Place of Origin: ZhangJiaGang City,JiangSu Province of China
    Brand Name: Fill Pack
    Certification: CE,ISO
    Model Number: TB-150

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set for gallon bottle labeling machine
    Price: 5600-7600USD/SET
    Packaging Details: sea worthy packing
    Delivery Time: 5 - 15 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 15 Sets/Month
    Contact Now
    Detailed Product Description
    Size: 1000*800*2000mm Material Of Label: PVC、 PET、 OPS
    Key Word: Gallon Bottle Labeling Machine Diameter Of Label: ∮28mm-∮125mm
    Length Of Label: 30mm-250mm Automatic Grade: Automatic
    Driven Type: Electric Warranty: 12 Months

    0-50BPM stainless steel gallon bottle labeling machine PLC control

    Product Description

    Whole gallon bottle labeling machine frame is made out of stainless steel SUS304. The frame is simple, beautiful, waterproof and not rust.This type of machine has the function of bottle carrying ,bottle separation ,label sleeving and label shrinking and it is perusing high speed ,exact location fewer worker and perfect packaging. It can apply to food and beverage industry and has the function of beauty and easily maintain. It is easy for cleaning.Gallon bottle labeling machine is a high efficiency, high precision sleeve standard electronic equipment, greatly increasing the standard accuracy and aesthetic standards, at the same time, a relatively high degree of automation, involving less manual work.

    0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control



    The main configuration table and function of gallon bottle labeling machine

    Name

    Function

    Material offering group

    Offer motor for label carrier

    Shelf group

    Install volume label device

    Platform elevating group

    Adjust the height of host automatically according to the bottle shapes

    Brush-off group

    Brushing the cutted label on the bottle

    Cutter group

    Cutting off the labels which are sent to Center guide pin

    Cutter controlling group

    Control the cutter operational site

    The back drive group

    Offer motor for label of center guide pin

    The front drive adjusting group

    Grasping the center guide pin

    Frame of Electric eye group

    Adjust the best cutting position of the label

    Electric eye of bottle lighting detecting group

    Adjust the sleeve labeling position of bottle body

    Hairbrush group

    Brush the label which cannot sleeve properly to the right place

    Bottle positioning group

    Make bottle stable, control sleeve labeling position

    Center guide pin group

    Make volume label distracted for transfer and cut easily

    Bottle entering screw bolts

    Separate bottle on equal distance in order to sleeve labeling accurately

































































    Detailed Images

    Voltage :1, Host machinez;AC220V, 50/60HZ, 1.5-2KW, single-phase

    2,Shrinking machine :AC380V, 50/60HZ ,9KW(electrical heat ) / three phase

    Production speed :

    Diameter of label :∮28mm-∮125mm

    Length of label : 30mm-250mm

    Thickness of label: 0.035mm-013mm

    Material of label:PVC, PET, OPS

    Size: 1000*800*2000mm

    0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control



    Configuration table of machine parts

    1. Bottle positioning mechanism

    1set

    5. Label carrier drive mechanism

    1set

    2. Single material putting place

    1set

    6. Cutter mechanism

    1set

    3. Fiber-optical electric eye controlling

    1set

    7. Automatic platform elevating mechanism

    1set

    4. Center guide pin

    1set

    8. Man-machine interface of operation control panel

    1set

















    0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control



    After sales service:

    1.Installation & adjustment

            After the equipment are arrived at the customer’s site, the customer is responsible for unpacking and arranging the equipment according to the placement drawing; and does under our install-adjust    technicians’ guidance. Costs of the staff are decided at last.



    2. Training

    • We are responsible for offering the technical training to user. The training content includes the structure and maintenance of the equipment, control and operation of the equipment. Through training, users' technical staff can grasp and the skill of operation and maintenance proficiently, and deal with the general troubles in time. We will appoint qualified technical staff for the guidance.
    • The buyer can send staff to our company for learning.



    3, Quality assurance

    • We guarantee the goods offered are brand-new, not used, with latest design and suitable material made, and we guarantee the specification of the equipment is consonance with the contract.
    • We guarantee the line achieve product technical performance indicators within 5 days after feeding operation through the correct guidance of the installation and commissioning.
    • We are responsible for the fault and damage of the production line caused by our design, technology, manufacture, installation, adjustment and material defect etc. that all belong to our responsibility.
    • The warranty period is 12 months after acceptance check of the production line. If there is any different between the furnished equipment in the customer’s factory and the equipment concerned in the contract, the users have the right to pass the inspection book to the legal department to claim for compensation to our company within goods warranty period.

    0-50BPM Stainless Steel Gallon Bottle Labeling Machine PLC Control

    please kindly click the play button to watch the video
