500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Washing Filling Capping Equipment / Plant / Machine / System / Line
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001 - 2008 |
| Model Number: | CGF40-40-10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 20000-40000USD |
| Packaging Details: | Wooden Case Package |
| Delivery Time: | 30 Working Days After Deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 15 Sets Per Months |
|
Detail Information |
|||
| Control: | PLC+ Touch Screen | Dimension(L*W*H): | 2450*2100*2400 Mm |
|---|---|---|---|
| Driven Type: | Electric 380V 50Hz | Type: | Filling Machine |
| Highlight: | water bottle filling machine,water filler machine |
||
Product Description
★The most advanced technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is used.The filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
★Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.
★1.monoblock washing filling capping machine Except the down framework, the transmission parts and some parts that must be made of special materials. Other spare parts are made of stainless steel 304.
★2.The motivation is derived from the driven system in the framework passed by gear.
★1) monoblock washing filling capping machine Adopted Germanyanti-corrosion non-maintaining bearing that can reduce the pollution of filling to the environment.
★2) The liquid supply adopts the automatic pneumatic valve magnetic liquid-level switch to control the liquid tank automatically.
This monoblock washing filling capping machine is the highest degree of accuracy of 3 in 1 machine, it is important for the machine to run stably and the product quality.
★ There are aseptic nozzles between the transition poking wheel and filling parts to rinse the product rested in the bottleneck screw parts.
|
Parameters
|
|
| Model | CGF40-40-10 |
| Capacity(B/H) | 20000 |
| Bottle size | Neck :φ50-100mm:Height:150-320mm |
| Water pressure | 0.18-0.25Mpa |
| Water consumption(kg/h) | 1000 |
| Washing station | 18 |
| Loading-Dripping-discharge station | 2-2-2 |
| Filling precision | <+1MM |
| Air pressure | 0.5Mpa |
| Air consumption (m³/min) | 0.3 |
| Power(kw) | 7 |
| Weight(kg) | 4000 |
| Dimension(L*W*H)(mm) | 3860*3150*2400 mm |
|
Our Washing-filling-capping machines (3-in-1 and Linear type)
|
||||||
|
3in1(0-2L bottle)
|
Capacity(bottle per hour)
|
3in1(3-10L bottle)
|
Capacity
|
Linear type
|
Capacity
|
|
|
CGF8-8-3
|
2000-3000BPH
|
CGF8-8-3B
|
0-1000
|
CGF4-4-1
|
500BPH
|
|
|
CGF12-12-4
|
3000-4000BPH
|
CGF12-12-4B
|
0-1500
|
CGF6-6-1
|
750BPH
|
|
|
CGF18-18-6
|
6000-7000BPH
|
CGF18-18-6B
|
0-2500
|
CGF8-8-1
|
1000BPH
|
|
|
CGF24-24-8
|
11000-12000BPH
|
CGF24-24-8B
|
0-3500
|
CGF10-10-1
|
1500BPH
|
|
|
CGF32-32-10
|
14000-15000BPH
|
CGF32-32-10B
|
0-5000
|
CGF12-12-1
|
2000BPH
|
|
|
CGF40-40-10
|
19000-20000BPH
|
|
|
|
|
|
|
CGF50-50-12
|
23000-24000BPH
|
|
|
|
|
|
|
|
||||||
|
More capacities if you need, we can also customize that for you. please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.
|
||||||
