PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System

PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System

    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System
  • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: DCGF40-40-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 20000-50000USD
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H): 2980*2200*2250 Mm Weight: 4500KG
    Power: 7KW Packaging Type: PET Plastic Bottle
    Electrical Brand: Mitsubishi, OMRON, SIEMENS Capacity: 10000-15000BPH
    Voltage: 380V/220V 50HZ Processing: Japan & Germany


    Plastic bottle carbonated drink filling line DCGF40-40-12

    >>>Overview of Production Line:
    Based on the principle of reliable operation and reasonable economy of the system, relevant design standards and norms are adopted and compiled in combination with years of engineering experience of our company.
    ★A) Distribution system: raw materials are mixed into raw material slurry, and the tank body is made of food grade SUS304 stainless steel.
    ★B) Temperature bottle spraying equipment: the low-temperature filling bottle will be heated to the set temperature through this equipment, effectively prevent the phenomenon of bottle explosion, while ensuring the stability of gas content;



    >>>Design basis:
    ★1. Raw Water Quality Report: Required to be Provided by Users
    ★2. The design and manufacture of control equipment, measuring instruments and electrical equipment conform to relevant regulations and standards.
    PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System
    PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottle Filling Machine / Equipment / Plant / System
    Optional carbonated drink making machines in the carbonated filling line
    Drink carbonator
    Output
    Mixing precision
    Purity of CO2
    Dimension
    Weigh
    Power
    QHS-1000
    1T
    2%
    99.9%
    1000*900*1900mm
    500Kg
    1.5Kw
    QHS-3000
    3T
    2%
    99.9%
    2000*1400*2200mm
    1200Kg
    5.8Kw
    QHS-6000
    6T
    2%
    99.9%
    2100*1500*2270mm
    1350Kg
    6.3Kw
    QHS-9000
    9T
    2%
    99.9%
    2150*1400*2380mm
    1500Kg
    6.5Kw
    QHS-18000
    18T
    2%
    99.9%
    2000*1750*2400mm
    1950Kg
    7.2Kw

    Optional RO water treatment machines in the carbonated filling line
    Model
    Capacity(liter per hour)
    RO-1000
    1000LPH
    RO-3000
    3000LPH
    RO-5000
    5000LPH
    RO-6000
    6000LPH
    RO-10000
    10000LPH
    Optional plastic bottle carbonated filling machine in the carbonated filling line
    Model
    Capacity(bottle per hour)
    DCGF12-12-4
    1000-2000BPH
    DCGF18-18-6
    3000-4000BPH
    DCGF24-24-8
    6000-7000BPH
    DCGF32-32-10
    8000-10000BPH
    DCGF40-40-12
    10000-12000BPH

    If you need glass bottle carbonated filling line, please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.





    >>>The whole line including:

    Water treatment system



    Carbonated drink making part



    Drink cooling tank and Drink carbonator



    Bottle washing-fiiling capping machine
    ★ Our plastic bottle filling machine uses balanced pressure filling technology.This machine integrates washing, filling and capping parts into a 3-in-1 machine.
    ★ According to the number of washing head filling head and capping head, the speed of our filling machine have 2000BPH4000BPH6000BPH8000BPH etc. You just need to tell us the speed you need, and we can recommend you the right type machine.



    Carbonated drink bottle warmer
    Because carbonated beverages are filled at low temperature, in room temperature environment, moisture in the air condensates easily on the surface of bottles, causing serious damage to subsequent packaging and labeling. Therefore, after the filling machine, a thermos bottle machine must be set up to heat the bottle body to room temperature. The thermos bottle machine heates the bottle body by heat exchange of circulating spraying hot water. It has three permanent temperature zones .



    Labeling machine



    Code printer



    Film shrinking packing machine
