PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System

PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System

    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
  • PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: DCGFG12-12-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 20000-50000USD
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H): 2980*2200*2250 Mm Automatic Grade: Automatic
    Weight: 4500KG Power: 5KW
    Packaging Type: Glass Capacity: 1000-1200BPH
    Cap Style: Glass Bottle Processing: Japan & Germany


    Description of Glass bottle carbonated drink filling line DCGFG12-12-4

                                                              Assuring You of Our Best Machines
    We are committed to provide you with the exceptional carbonated filling line and helping you attain your requirements.

                                  Please feel free to contact us for more information of interest.


    >>>Overview of Production Line:

    The plastic bottle carbonated beverage production line consists of three parts:
    Material system (distribution and carbon dioxide mixing), filling system, packaging system.

    ★A) Beverage mixer: It is equipped with cold drinking water tank and refrigeration unit. High-power or ordinary mixer should be used according to the different gas content of beverage.
    ★B) Temperature bottle spraying equipment: the low-temperature filling bottle will be heated to the set temperature through this equipment, effectively prevent the phenomenon of bottle explosion, while ensuring the stability of gas content;


    >>>Design basis:
    ★ Equipment Flow:Water Making Equipment
    Material → Distribution System → Beverage Mixer → Filler → Conveyor Chain → Warm Bottle Machine → Lamp Inspection → Packaging Equipment → Finished Products

    PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
    PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
    PET Plastic Glass 3 In 1 Monobloc Aerated Drink Beverage Water Bottling Machine / Equipment / Line / Plant / System
    Optional carbonated drink making machines in the carbonated filling line
    Drink carbonator
    Output
    Mixing precision
    Purity of CO2
    Dimension
    Weigh
    Power
    QHS-1000
    1T
    2%
    99.9%
    1000*900*1900mm
    500Kg
    1.5Kw
    QHS-3000
    3T
    2%
    99.9%
    2000*1400*2200mm
    1200Kg
    5.8Kw
    QHS-6000
    6T
    2%
    99.9%
    2100*1500*2270mm
    1350Kg
    6.3Kw
    QHS-9000
    9T
    2%
    99.9%
    2150*1400*2380mm
    1500Kg
    6.5Kw
    QHS-18000
    18T
    2%
    99.9%
    2000*1750*2400mm
    1950Kg
    7.2Kw

    Optional RO water treatment machines in the carbonated filling line
    Model
    Capacity(liter per hour)
    RO-1000
    1000LPH
    RO-3000
    3000LPH
    RO-5000
    5000LPH
    RO-6000
    6000LPH
    RO-10000
    10000LPH
    Optional glass bottle carbonated filling machine in the carbonated filling line
    Model
    Capacity(bottle per hour)
    DCGFG12-12-4
    1000-2000BPH
    DCGFG18-18-6
    3000-4000BPH
    DCGFG24-24-8
    6000-7000BPH
    DCGFG32-32-10
    8000-10000BPH
    DCGFG40-40-12
    10000-12000BPH

    If you need plastic bottle carbonated filling line, please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.



    >>>The whole line including:

    Water treatment system



    Carbonated drink making part



    Drink cooling tank and Drink carbonator



    Bottle washing-fiiling capping machine



    Carbonated drink bottle warmer
    Because carbonated beverages are filled at low temperature, in room temperature environment, moisture in the air condensates easily on the surface of bottles, causing serious damage to subsequent packaging and labeling. Therefore, after the filling machine, a thermos bottle machine must be set up to heat the bottle body to room temperature. The thermos bottle machine heates the bottle body by heat exchange of circulating spraying hot water. It has three permanent temperature zones .



    Labeling machine

    ★Our company have all kinds of OPP Hot Glue Labeling Machine, Shrink Sleeve Labeling Machine, Cold Glue labeling machine and adhesive labeling machine.
    ★How to choose the labeling machine?Please tell us what kind of labels you use on the bottles? How many labels you need to stick on one bottle? What the shape of your bottles are? You better send me the bottle pictures if convenient.



    Code printer



    Film shrinking packing machine
