PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System

PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System

    • PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System
    • PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System
  • PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: DCGFG32-32-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 20000-50000USD
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H): 2980*2200*2250 Mm Weight: 4500KG
    Power: 7KW Packaging Type: Glass
    Application: Beverage Capacity: 8000-10000BPH
    Cap Style: Glass Bottle Color: Silver Gray


    Description of Glass bottle carbonated drink filling line DCGFG32-32-10

    >>>Design basis: ★1. Raw Water Quality Report: Required to be Provided by Users ★2. Beverage technological process: users are required to provide (our company can also provide related beverage formulations) ★3. Equipment Flow:Water Making Equipment Material → Distribution System → Beverage Mixer → Filler → Conveyor Chain → Warm Bottle Machine → Lamp Inspection → Packaging Equipment → Finished Products ★4. The design and manufacture of control equipment, measuring instruments and electrical equipment conform to relevant regulations and standards.

    PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System
    PET Plastic Glass 3 In 1 Monobloc Sparkling Water Wine Bottling Machine / Equipment / Line / Plant / System

    Optional carbonated drink making machines in the carbonated filling line
    Drink carbonator
    Output
    Mixing precision
    Purity of CO2
    Dimension
    Weigh
    Power
    QHS-1000
    1T
    2%
    99.9%
    1000*900*1900mm
    500Kg
    1.5Kw
    QHS-3000
    3T
    2%
    99.9%
    2000*1400*2200mm
    1200Kg
    5.8Kw
    QHS-6000
    6T
    2%
    99.9%
    2100*1500*2270mm
    1350Kg
    6.3Kw
    QHS-9000
    9T
    2%
    99.9%
    2150*1400*2380mm
    1500Kg
    6.5Kw
    QHS-18000
    18T
    2%
    99.9%
    2000*1750*2400mm
    1950Kg
    7.2Kw

    Optional RO water treatment machines in the carbonated filling line
    Model
    Capacity(liter per hour)
    RO-1000
    1000LPH
    RO-3000
    3000LPH
    RO-5000
    5000LPH
    RO-6000
    6000LPH
    RO-10000
    10000LPH
    Optional glass bottle carbonated filling machine in the carbonated filling line
    Model
    Capacity(bottle per hour)
    DCGFG12-12-4
    1000-2000BPH
    DCGFG18-18-6
    3000-4000BPH
    DCGFG24-24-8
    6000-7000BPH
    DCGFG32-32-10
    8000-10000BPH
    DCGFG40-40-12
    10000-12000BPH

    If you need plastic bottle carbonated filling line, please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.





    >>>The whole line including:

    Water treatment system
    ★ Automation grade: Automatic / Semi-automatic
    ★ Capacity range: 250L—30T per hour can be chosen.
    ★ Material of three pre-filters:SUS304 / FRP
    ★ Membrane brand: HYDECANME/DOW/GE OSMONICS/Saehan/Toray
    ★ Optional device: water tank, sodium ion exchanger,UV sterilizer,water storage tank
    ★ Water pump:NangFang pump



    Carbonated drink making part



    Drink cooling tank and Drink carbonator



    Bottle washing-fiiling capping machine



    Carbonated drink bottle warmer



    Labeling machine



    Code printer



    Film shrinking packing machine
    ★The film shrink packing is used to pack scattered bottles into a whole group.We have Manual wrapping Shrink Packing Machine, Semi-Automatic PE Film Heat Shrink Packing Machine, L Type Automatic PE Film Heat Shrink Wrapping Machine,Linear type High Speed Automatic Shrink Packing and Color film orientation shrink packing machine.
    ★How to choose the machine? You need to tell us what kind of film you need and what kind of bottle arrangement you need.
