Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Treatment Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Treatment Equipment / Plant / Machine / System

Product Details:

Place of Origin: ZhangJiaGang City, JiangSu Province, China
Brand Name: FillPack
Certification: CE,ISO
Model Number: Filter-FRP

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Blanket cloth or wooden case pacakge
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 50 sets/month
Get Best Price Contact Now

Detail Information

Working Pressure: 150 Psi Application: Pure Water
Condition State: New Usage: Pure Water Process
High Light:

ro water purifier machine

,

water purifying systems

Product Description

Description of our FRP Mechanical pre-filters of water treatment system



A)Material:
(a). inner shell – Polyethylene (PE) seamless one-piece tank liner
(b). Outer shell – Continuous strands of fiber-glass with high strength epoxy resin
(c). Bottom base – FRP reinforced tripod base
(d). Opening – 2.5" & 4" precision injected model with threaded opening for 8 " to 36" diameter tanks
(e). Opening – 6 "Aluminum flange (anti-corrosion coating) opening for 36” to 63” diameter tanks
B)Working Pressure: (a)≤1.0MPa(150PSI)
C)Working Temperature :≤49°C
D)Maximum Vacuum :127mmHg(5"Hg).
E)Maximum Temperature :40C (104F)
F)Certificates:CE ;NSF ; ISO9001 etc.
G)Media : water

Application:
All feed water and waste water treatment application, included multi-media filter and softener.



Mineral / pure drinking water ion exchanger / precision / cartridge treatment equipment / plant / machine / system

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Treatment Equipment / Plant / Machine / System 0

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Treatment Equipment / Plant / Machine / System 1

Parameters of our FRP Mechanical pre-filters:

Mineral / Pure Drinking Water Ion Exchanger / Precision / Cartridge Treatment Equipment / Plant / Machine / System 2

The FRP Mechanical pre-filters are matched with water treatment:

Model Size Used for Water treatment machine
818 200X450 0-100LPH
835 200X 875 100-250LPH
844 200X1100 100-250LPH
942 200X1050 250-500LPH
1035 250X875 250-500LPH
1054 250X 1350 250-500LPH
1252 300X 1300 500-1000LPH
1354 325X 1350 1000-1500LPH
1465 350X 1625 1000-1500LPH
1665 400X1625 1500-2000LPH
1865 450x1625 2000-2500LPH
