Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Purifying Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Purifying Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Purifying Equipment / Plant / Machine / System

Product Details:

Place of Origin: ZhangJiaGang City, JiangSu Province, China
Brand Name: FillPack
Certification: CE,ISO
Model Number: Filter-SS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Blanket cloth or wooden case pacakge
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Contact Now
Detailed Product Description
Product Name: Stainless Steel Filter Tank Weight: 10-500Kg
Capacity: 20L To 20000L Usage: Pure Water Process



Description of our Stainless Steel Mechanical pre-filter system



Filter Media Types:

1, Sand is the most common filter media. Generally, fine mesh sand is coupled with a course grain support bed to remove suspended solids and turbidity. Graded in various ranges, CHUNKE sand can be used as filtration medium or underbedding depending on particle size and application.

2, Gravel has a highly spherical shape that promotes good flow and even distribution in support beds.

3, Calcite media is specially graded calcium carbonate compound for neutralizing acid with consistent dissolving rates for water treatment.

4, Manganese Greensand media is treated siliceous material for treating water containing iron, manganese and hydrogen sulfide through oxidation.

5, Anthracite is recommended as a filter medium where additional silica in the water is not desirable and can remove lighter weight turbidity. Anthracite is typically used in applications where silica pick-up is undesireable.

6, Activated carbon medium is used to remove taste, odor, organic contaminants, and chlorine as well as being used in many drinking water applications.

7, ProSand is based on a rare natural mineral. Its unique properties radically improve the performance and cost of media filtration.

8, Multimedia is required when maximum quality water is required and unwanted sediment is too small to be removed by standard media. It consists of multiple layers of increasing grain size to remove sediment as small as 10 microns.



Parameters of Mechanical filter with stainless steel shell:

Flow Model Thickness (mm) Dimension(mm)
4m³/H SUS400 2mm Φ400X1850mm
6m³/H SUS500 2mm Φ500X2100mm
9m³/H SUS600 3mm Φ600X2500mm
10m³/H SUS700 3mm Φ700X2600mm
12m³/H SUS800 3mm Φ800X2600mm
14m³/H SUS1000 3.5mm Φ1000X2700mm
16m³/H SUS1100 3.5mm Φ1100X2700mm
18m³/H SUS1200 3.5mm Φ1200X2700mm
22m³/H SUS1400 4mm Φ1400X2800mm
30m³/H SUS1600 4.5mm Φ1600X2900mm
60m³/H SUS2000 5mm Φ2000X3500mm
80m³/H SUS2500 6mm Φ2500X5000mm



Mineral / pure drinking water silica / Quartz sand / Active carbon purifying equipment / plant / machine / system

Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Purifying Equipment / Plant / Machine / System



Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Purifying Equipment / Plant / Machine / System
