Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Treatment Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Treatment Equipment / Plant / Machine / System

Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Treatment Equipment / Plant / Machine / System

Product Details:

Place of Origin: ZhangJiaGang City, JiangSu Province, China
Brand Name: FillPack
Certification: CE,ISO
Model Number: Filter-SS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Blanket cloth or wooden case pacakge
Delivery Time: 15-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50 sets/month
Contact Now
Detailed Product Description
Application: Pure Water Condition State: New
Usage: Pure Water Process



Description of our Stainless Steel Mechanical pre-filter system



Activated carbon filter

   Activated carbon filter is used for the remove color, taste, residual chlorine and organics mainly by adsorption. activated carbon is an artificial sorbent. Its cell-hole structure and huge superficial area, which has a strong adsorption capacity for the dissolved organics in the water, such as benzene and phenolic compounds.besides,
   It shows strong removal efficiency for organic pollutants which is hard to be removed by biological and chemical methods, such as chroma, stench, surfactants, synthetic detergents and dyes, etc.Granular activated carbon material is able to remove 85% of Ag + , Cr2 + and Cr04-2 in the water .after the raw water flows through the activated carbon filter bed, the suspended solid in the water will be less than 0.1 mg/L, COD removal rate is generally 40% to 50% and free chlorine is less than 0.1mg/I. It can be used as pretreatment of ion exchange, electrodialysis and reverse osmosis in pure water technology so as to remove organics, colloids and residual chlorine; it can be also used as an advanced treatment method after the secondary treatment section to ensure the quality of reuse water.



Parameters of Mechanical filter with stainless steel shell:

Flow Model Thickness (mm) Dimension(mm)
4m³/H SUS400 2mm Φ400X1850mm
6m³/H SUS500 2mm Φ500X2100mm
9m³/H SUS600 3mm Φ600X2500mm
10m³/H SUS700 3mm Φ700X2600mm
12m³/H SUS800 3mm Φ800X2600mm
14m³/H SUS1000 3.5mm Φ1000X2700mm
16m³/H SUS1100 3.5mm Φ1100X2700mm
18m³/H SUS1200 3.5mm Φ1200X2700mm
22m³/H SUS1400 4mm Φ1400X2800mm
30m³/H SUS1600 4.5mm Φ1600X2900mm
60m³/H SUS2000 5mm Φ2000X3500mm
80m³/H SUS2500 6mm Φ2500X5000mm



Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Treatment Equipment / Plant / Machine / System



Mineral / Pure Drinking Water Silica / Quartz Sand / Active Carbon Treatment Equipment / Plant / Machine / System
