Automatic Single Head Sleeve Labeling Machine 150BPM 250BPM With Shrink Tunnel

Product Description

Single head sleeve labeling machine

General:

Whole machine frame is made out of stainless steel SUS304. The frame is simple, beautiful, waterproof and not rust. It is easy for cleaning.

The special cutting system: adopting the whist and con-volute technology. The label cutting is flat, no burr.The label location set assures the sleeving veracity.

Adopting model group design, module controlled; Achieve veracity and fast sleeving.

With the good quality touching operation screen, achieving operation by finger, easy and shortcut.

It is a high automatic packing machine. Just one person handles, easy operation.

Easy to change packing material, the change over of the mould can be easily done by hand without any tools.

Within the flat width limitation, can be used to package objects in different shape, no matter round or square, can be applied on glass or plastic bottles.

Higher safely and stability for operation and saving time of manpower.

Working process:

Specifications:

This type of machine has the function of bottle carrying ,bottle separation ,label sleeving and label shrinking and it is perusing high speed ,exact location fewer worker and perfect packaging. It can apply to food and beverage industry and has the function of beauty and easily maintain.

Synchronized transmission, any change of transmission belt will be finished quickly. Compared to the type of traditional multilayer whose change and maintain need more than six hours ,it’s maintenance is easy and maintain is simple ,so it doesn’t influence production.

Unit cutter head plane design in China which apply to the container of ∮30mm—∮130m(TB-250 requires 2 cutter heads) .you never need to change or debug it. It also has unique light touch human-machine screen, that means, auto search original location as well as safety and continence which is ahead of other similar products.

Single shrinking label feed plane ,tension height which is continent to fix the label; micro-computer auto figure which avoid enactment and adjustment .you only need to press it lightly ,the label will detect and locate automatically. The change of label is quick and convenient, besides,the cut place is absolutely exact .

Label feeding equipment: TB-100 driving synchronized tensity control the supply of label ,the supply ability is 1.5meters per minute(TB-250,the supply ability is 2meters per minute), volume label supply plane is ∮500mm,the internal diameter of paper tube will be 4’ ,8’,10’ .the configuration of label feeding is stable tensity which enable the exact length of label and the stable ,quick supply of label.

The center pillar applies step by step shoot label structure and the speed is 250B-300B per minute.

The newly designed cutter head use step by step motor driving which speed is high ,action is exact, the cut is in order and the shrinking is beautiful. This design cooperate with the label synchronized location structure enable the precision of cut location within 1mm.

Many emergency stop buttons enable emergency stop at the proper position along the production which guarantee the safe production.

Special designed heat wind shrinking tunnel use high pressure wing machine which makes the shrink effect perfect. Compare with the traditional shrink tunnel which cannot shrink curved bottle, this head wind shrink tunnel can make the shrink effect satisfying.

The new style steam shrink tunnel improve the efficiency highly . It applies to different and equal round bottle, flat bottle, square bottle etc. The adjustment and maintain is convenient, the shrink is in order. The spout of steam use uses the separation style which makes the tunnel smooth. The spout mouth is divided into four parts and the height ,place and quantity of steam of every part can be adjusted in order to make the shrink effect perfect .the low pressure steam bag use the seamless steel tube design and every connect tube use stainless steel soft tube ,so the dis-assembly and fixing id very convenient. The whole machine is made of stainless steel ,so it is heat preservation and save energy sources, besides ,it accord with the international safety standard. The stainless steel plane at the bottom can condensate water and drainage them.there are two eye window in front and at the back of the box body. the waterproof design of the whole machine is made of stainless steel which makes the operation and maintain convenient.

Parameters:

Voltage:Host machines;AC220V, 50/60HZ, 1.5-2.5KW, single-phase

TB-150 Speed: 150BPH

TB-250 Speed: 250BPH, speed slightly faster when label is shorter

Diameter of bottle body: ∮28mm-∮125mm

Length of label: 30mm-250mm

Thickness of label: 0.035mm-0.045mm

Material of label:PVC, PET, OPS

Applicator size:L2000MM*W850MM*H2000MM

Detail image:

Internal structure of the machine for ref.

TB-150 Design layout for ref

1.2 Steam shrink tunnel:

Made of SUS304 stainless steel. The equipment is with steam controller for steam blow wastage. Remained steam be brought out to plant through wind motor. Steam press is adjustable. Shrink effect is perfect and will not hurt the label.

Parameters:

Power:3PH,380V, 50HZ 0.25kw

Dimension: 1500*700*2000mm(SB-1500)

2000*700*2000mm(SB-2000)

Pressure: 0.4-0.7Mpa
