PET / Tin Can Carbonated Drink Filling Machine , Full Automatic Filling Capping Machine

PET / Tin Can Carbonated Drink Filling Machine , Full Automatic Filling Capping Machine

Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FillPack
Certification: CE & ISO & TUV & SGS
Model Number: DG-12
Color: Silver Gray
Control: PLC Control With Touch Screen
Processing: Japan & Germany
Suitable Bottle Size: 0.3-2L PET Bottle
Cap Style: Aluminum
Capacity: 3000-4000BPH
Electrical Brand: Mitsubishi, OMRON, SIEMENS
Warranty: 1 Year for Spare Parts

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden Case Package
Delivery Time: 30 Working Days After Receiving Your Deposit Payment
Payment Terms: TT & L/C
Supply Ability: 20 sets/month
Get Best Price Contact Now

Detail Information

Highlight:

soft drink bottling equipment

,

csd filling machine

Product Description

PET / Tin Can Carbonated Drink Filling Machine , Full Automatic Filling Capping Machine





Quick Detail:



Name: Full Automatic Filling Capping Machine Carbonated Drink Production Line for PET / Tin Can

Material: Food stage stainless steel
Control: PLC & touch screen control
Capacity: 6000-10000bph
Suitable Bottle: PET can / Tin can
Bottle Volume: 0.2-0.6L
Dimension: By order
Function: Washing filling capping 3 in 1
Technology: Germany & Japan
After-sales service provided: Engineers available to service machinery overseas .





Description:



1. This series equipment is used in producing all kinds of carbonated drink contained with tin cans or PET cans. Filling, sealing can be carried out on the same machine. The design of the machine is scientific and reasonable. The appearance is beautiful and the function is complete. Its operation and maintenance is convenient. Its automation is high.

2. The advanced technology from Germany and Italy are employed. The speed of filling is fast and the liquid amount is controlled accurately. The filling device can be stopped automatically when there is no bottle or bottles are damaged. The advanced auto-washing technology is used in the system.

3. Pneumatic value and damped gears are used for bottle conveying, the noise is low and the whole machine runs smoothly.

4. The magnetic torque is used for screw capping. The power of capping can be adjusted without steps. The power of the screw capping can also be fixed. The caps can’t be damaged, the capping is reliable.

5. Horizon swirl air power caps sorting device is used to avoid damaging the surface of caps, and when there is a shortage of caps in the caps storage cage, an alarm signal will be generated and the caps will be fed automatically.

6. The whole machine is controlled by PLC with touch-screen as the interface between human and machine. The amount of the drinks in the drink tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or caps are not available, the machine can be stopped automatically.





Specifications:



Model : DG -8 DG -12 DG-18 DG -24
Production Capacity: 1000-2000b/h 1000-3000b/h 2500-4600b/h 2500-6000b/h
Bottle standard: Glass bottle, PVC bottle, Pop-top can
Filling Pressure: 0.2-0.3Mpa
Filling Temperature: 2-6°
Power: 0.75kw 1.1kw 1.5kw 1.5kw
Overall Dimensions: 1000×900×1800 mm 1100×1050×1800 mm 1400×1300×1800 mm 1600×1540×1800 mm
Weight : 1000kg 1600kg 2100kg 2700kg











Competitive Advantage:



1. One year warranty for the whole system

2. Free equipment installation and debugging

3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

4. Every 3 years, we can help to overhaul the machine free (Labor)

5. We can provide internship service and help you train the operator and mechanic

6. Free production technology and process configuration

7. We can help you to design the production line, workshop and provide turn-key project





Company description



    Zhangjiagang City FILL-PACK Machinery Co., Ltd. is a manufacturer enterprise specializing in producing beverage packing equipment and various water treatment equipment. The company has not only gained over ten year’s producing experience but also incorporated advanced technology from home and abroad. So we have won high reputation among our customers domestic and abroad.



    At present we produce: production lines for mineral water, pure water, fruit juice, tea drink, milk drink and carbonated drink with capacity 1000-20000bottles/hour, production lines for vinegar, soy sauce and wine, 3-5gallon barreled water with capacity 80-120 barrels per hour and various water treatment plant.



    Honesty, Sincerity, and good faith" is our spirit, while "High technology, high quality, and high level" is what we look for. We try our best to satisfy our customers' needs with our good after-sales service. We would like to cooperate with our friends and develop together. All friends from at home and abroad are warmly welcomed to visit us.





Market Distribution:



Market Revenue(Previous Year) Total Revenue (%)
Africa confidential 40%
Middle east confidential 15%
America confidential 5%
Euro confidential 4%
Middle Aisa confidential 3%
South-east Asia confidential 3%
Domestic confidential 30%
