Drink Processing Manual Bottle Labeling Machine For Bottles , Shrinking Tunnel
Product Details:
| Place of Origin: | China,JiangSu,Zhangjiagang |
| Brand Name: | FillPack |
| Certification: | CE. ISO9001 |
| Model Number: | TB |
| Material: | SUS304 |
|---|---|
| Label type: | Sleeve label |
| Suitable bottle: | Plastic bottle / Glass bottle |
| Operation mode: | Manual |
| Shrinking type: | Steam / electric |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set/pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Sea worthy package |
| Delivery Time: | 15-20 days after deposit receipt |
| Payment Terms: | TT / LC / |
| Supply Ability: | 2 sets / month |
|
Detail Information |
|||
| High Light: | automatic labeling machine,sticker labeling machine |
||
|---|---|---|---|
Product Description
Drink Processing Manual Bottle Labeling Machine For Bottles , Shrinking Tunnel
Quick Detail:
1, Operation mode: Manual operation / Automatic shrinking
2, Bottle height: no limitation
3, Bottle diameter: no limitation
4, Label material: PVC / PET
Description:
The manual type labeling machine is composed by manual labeling table and shrinking tunnel.
Manual labeling table: It is made of SUS304, and welded on both side of the conveyor. Bottles are going through the conveyor, workers take the bottle to the table for putting the sleeve labels onto bottles. And then put the bottles to the cnveyor again.
Shrinking tunnel: There are two types, one is steam shrinking type; the other is electric shrinking type.
Steam shrinking type: It is made by SUS304, there are several steam tubes in the tunnel and connect to the steam generator. The steam generator is seleced according to the capacity.
Electric shrinking type: The tunnel is made of coated carbon steel. There are several heating tubes installed in it.
Specifications:
| Manual labeling table | |
| Material | SUS304 |
| Size (Length * width) | 500*250 (each side) / Customize |
| Steam shrinking tunnel | |
| Material | SUS304 |
| Size (Length * Width) | 1200*450mm |
| Elecric shrining tunnel | |
| Material | Coated carbon steel |
| Size (Length * Width) | 1000*300mm |
| Heating tube | 40w |
| Steam generator | |
| Heating power |
3kw/6kw/9kw/12kw/18kw/24kw/36kw/ 48kw/60kw/72kw/100kw/150kw/248kw |
|
Rated steam output |
4.3kg/h/8.6kg/h/12.9kg/h/17.2kg/h/25.8kg/h/34.4kg/h/ 51.5kg/h/68.8kg/h/86kg/h/103kg/h/143kg/h/215kg/h/358kg/h |
| Voltage | 220-380V |
| Rated working pressure | 0.4-0.7Mpa |
| Saturated temperature | 151-172 degree |
| water pump power | 220V ; 0.55-0.75kw |
| steam volume | Continuous |
Competitive Advantage:
1. One year warranty for the whole system
2. Free equipment installation and debugging
3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
4. Every 3 years, we can help to overhaul the machine free (Labor)
5. We can provide internship service and help you train the operator and mechanic
6. Free production technology and process configuration
7. We can help you to design the production line, workshop and provide turn-key project
