Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH

Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH

    • Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH
    • Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH
    • Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH
    • Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH
  • Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: YFRG18-18-6
    Color: Silver Gray
    Control: PLC Control With Touch Screen
    Processing: Japan & Germany
    Suitable Bottle Size: 0.3-2L Glass Bottle
    Cap Style: Metal Caps
    Capacity: 6000-8000BPH
    Electrical Brand: Mitsubishi, OMRON, SIEMENS
    Warranty: 1 Year for Spare Parts

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: TT & L/C
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description





    Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH





    Quick Detail:



    Name: Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH

    Material: Food stage stainless steel
    Control: PLC & Touch screen control
    Capacity: 6000-8000bph
    Suitable Bottle: Glass bottle
    Bottle Volume: 0.3-2L
    Dimension: By order
    Function: Washing filling capping 3 in 1
    Technology: Germany & Japan
    After-sales service provided: Engineers available to service machinery overseas .





    Description:



    1. This glass bottle juice tea bottling filling machine is  used for green tea, black tea, oolong tea, juice drink filling and sealing.

    2. It integrates glass bottle washing, juice filling and capping together. The design is scientific and reasonable. Its appearance is beautiful. Its operation and maintenance is convenient.

    3. The automation is high. It is good equipment for choosing hot drink bottling machine.

    4. The juice machine adopts block bottle neck hanging work state design and bottling valve rise drop design. It can meet the requirements of hot bottling of below 95 degrees Celsius.

    5. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and easier.

    6. The main juice drink filling machine adopts advanced PLC control technology. The key electric elements adopt international famous products.

    7. It is the best choice for the glass bottle juice bottling plant makers.



    Specifications:



    Model RCGF12-12-4 RCGF18-18-6 RCGF24-24-8 RCGF32-32-10 RCGF40-40-12
    Production(B/H)(500ml) 4000-5000 6000-8000 8000-12000 12000-15000 16000-20000
    Bottle standard Neck: φ50-100mm; Height: 150-320mm
    Water pressure of washing bottle 0.18-0.25Mpa
    Water consumption for washing bottle(kg/h) 1300 2000 3000 4000 5000
    Spraying position 4 7 10 14 18
    Dripping bottle position 3 5 8 10 15
    Filing precision +5MM
    Gas source pressure 0.4Mpa

    Gas consumption

    (m³/min)

    0.3 0.4 0.5 0.7 0.8
    Total power(kw) 4.2 4.5 5 6.2 7.8
    Total weight(T) 2 2.5 3 4 6
    Dimension (L*W*H)(mm) 2100*1600*2100 2500*1750*2100 2700*2100*2100 3500*2100*2100 3800*2200*2200











    Competitive Advantage:



    1. One year warranty for the whole system

    2. Free equipment installation and debugging

    3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

    4. Every 3 years, we can help to overhaul the machine free (Labor)

    5. We can provide internship service and help you train the operator and mechanic

    6. Free production technology and process configuration

    7. We can help you to design the production line, workshop and provide turn-key project





    Company description



       Zhangjiagang City FILL-PACK Machinery Co., Ltd is a manufacturer enterprise specializing in producing beverage packing equipment and various water treatment equipment. The company has not only gained over ten year’s producing experience but also incorporated advanced technology from home and abroad. So we have won high reputation among our customers domestic and abroad.



        At present we produce: production lines for mineral water, pure water, fruit juice, tea drink, milk drink and carbonated drink with capacity 1000-20000bottles/hour, production lines for vinegar, soy sauce and wine, 3-5gallon barreled water with capacity 80-120 barrels per hour and various water treatment plant.



        Honesty, Sincerity, and good faith" is our spirit, while "High technology, high quality, and high level" is what we look for. We try our best to satisfy our customers' needs with our good after-sales service. We would like to cooperate with our friends and develop together. All friends from at home and abroad are warmly welcomed to visit us.





    Market Distribution:



    Market Revenue(Previous Year) Total Revenue (%)
    Africa confidential 40%
    Middle east confidential 15%
    America confidential 5%
    Euro confidential 4%
    Middle Aisa confidential 3%
    South-east Asia confidential 3%
    Domestic confidential 30%



    Glass Bottle Filler Machine Automatic Juice / Tea Bottling Filling Machine 6000 - 8000BPH

    please kindly click the play button to watch the video
