Hot Melting Glue Bottle Labeling Machine , OPP Labeling Machine
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001:2008 |
| Model Number: | OPP-300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotation |
| Packaging Details: | Sea worthy packing material |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T, L/C, |
| Supply Ability: | 10 sets / month |
|
Detail Information |
|||
| Processing Type: | Bottle Labeling Machine | Control Manner: | PLC Control |
|---|---|---|---|
| Labeling Manner: | Hot Melting Glue | Warranty: | 1 Year |
| Condition: | New | Service: | Engineer Available To Be Abroad |
| High Light: | automatic labeling machine,sticker labeling machine |
||
Product Description
Hot Melting Glue Bottle Labeling Machine , OPP Labeling Machine
Quick Detail
1, Control manner: PLC control
2, Labeling manner: Hot melting glue labeling machine
3, Bottle type: various containers
Characteristics
- PLC control system, full-automatic working
- Horizontally adjustable main engine, vertically adjustable main engine (adjustment for label position)
- Include such mechanisms as label-providing, belt-conveying, label-cutting, wheel-attaching, vacuum-adsorbing, hot sol-conveyance
- Alarm for missing label or gap and alarm for label running-out
- Automatic label length controller to adjust position of I-MARK
- Vacuum drum made of high rigid material to reduce friction and static
Parameters
| Labeling percision | +-1mm |
| Speed | 300BPH |
| Power | 50HZ 3ph 380V |
| Total power | 7kw |
| Main motor | 1.5kw |
| Vacuum pump | 1.5kw |
| Gluing machine | 2.0kw |
| Hot melting machine | 1.7kw |
| Size | 4000*1500*2000mm |
| Weight | 1500kg |
| Air source | 4-6kg/cm2 |
| Air consumption | 0.1N m3/min |
| Air inlet | 3/8 inch |
| Operating condition | temperature 20-30 degree (keep in dry place at the room's temperature) |
please kindly click the play button to watch the video
