Monoblock 3 in 1 10000BPH Pet Bottle Tea Hot Filling Machine

Monoblock 3 in 1 10000BPH Pet Bottle Tea Hot Filling Machine

Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FillPack
Certification: CE & ISO & TUV & SGS
Model Number: RCGF 24-24-8

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden Case Package
Delivery Time: 30 Working Days After Receiving Your Deposit Payment
Payment Terms: TT & L/C, , MoneyGram
Supply Ability: 20 sets/year
Get Best Price Contact Now

Detail Information

Machine Type: Tea Hot Filling Machine Filling Temperature: 85 Degree
Machine Structure: 3 In 1 Filling Machine Material: SUS304
Control Manner: PLC Control Option: Recycling System
High Light:

coffee filling machine


aseptic filling machine

Product Description

Monoblock 3 in 1 Tea Hot Filling Machine 10000BPH Pet Bottle



Quick Detail:


Name: High Capacity Hot Filling Machine Concentrated Juice Commercial Bottling Equipment

Material: Food stage stainless steel 304 or 316

Filling type: Hot filling machine / Normal pressure filling machine
Control: PLC & touch screen control
Capacity: 6000-8000bph




- Tea hot filling machine concentrated juice / tea commercial bottling equipment;


- Washing, filling and capping are integrated in one machine which is called 3 in 1 hot filling machine;


- The most advanced technology from Japan and Germany is employed in the design;


- The empty bottles can be turned over 180~ along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.








Model RCGF12-12-4 RCGF18-18-6 RCGF24-24-8 RCGF32-32-10
Production B/H(600ml) 4000-5000 6000-8000 8000-12000 12000-15000
Bottle standard Neck:φ50-100mm Height150-320mm
Water pressure of washing bottle 0.18-0.25Mpa
Water consumption for washing bottle (kg/h) 1300 2000 3000 4000
Spraying position 4 7 10 14
Dripping bottle position 3 5 8 10
Filing precision +5MM
Gas source pressure 0.4Mpa
Gas consumption(m³/min) 0.3 0.4 0.5 0.7
Total power(KW) 4.2 4.5 5 6.2
Total weight (T) 2 2.5 3 4
Dimension (L*W*H)mm 2100*1600*2100 2500*1750*2100 2700*2100*2100 3500*2100*2100



Competitive Advantage:


1. One year warranty for the whole system

2. Free equipment installation and debugging

3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

4. Every 3 years, we can help to overhaul the machine free (Labor)

5. We can provide internship service and help you train the operator and mechanic

6. Free production technology and process configuration

7. We can help you to design the production line, workshop and provide turn-key project
