10000BPH Non-Carbonated Plastic Water Bottling Machine With CIP Cleaning Head
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001 - 2008 |
| Model Number: | RCGF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Sea worthy Package |
| Delivery Time: | 20 Working Days After Deposit |
| Payment Terms: | TT & L/C |
| Supply Ability: | 20 Sets Per Year |
|
Detail Information |
|||
| Machine Structure: | Monoblock Filling Machine | Filling Type: | Bottle Filling Machine |
|---|---|---|---|
| Filling Liquid: | Juice / Tea / Energy Drink | Electric Parts: | All Well-known Brand |
| Material: | SUS304 | Filling Range: | 330ml-1500ml |
| Highlight: | aseptic filling line,water bottling equipment |
||
Product Description
10000BPH Non-Carbonated Plastic Water Bottling Machine With CIP Cleaning Head
Quick Detail:
Machine structure: 3 in 1 filling machine
Capacity: 8000-1000 BPH
Filling type: Normal pressure filling machine / hot fillingmachine
Bottle type: 0.2-1.5L plastic bottle
Cap type: plastic screw caps
Filling material: Juice / Tea drink / energy drink
Description:
The tea bottling machine is monoblock filling machine which integrate washing, filling and capping machine in one unit. It is used to fill pure water, mineral water, and other non-carbonated water into plastics bottles. The bottles can be various, but the bottle mouth must be the same so that they can be used in one machine.
Features:
- Integrate bottle washing, liquid filling, bottle capping in one unit;
- Filling type:tea bottling machine/ Hot filling machine / normal pressure filling machine;
- Apply CIP cleaning head for washing pipes, liquid cylinder, valves etc after working;
- All electric parts can be customize;
- The bottle filling machine will be designed and developed basing on client's sample bottles, caps and capacity;
Specifications:
| Model | RCGF8-8-3 | RCGF12-12-4 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 |
| Washing Head No | 8 | 12 | 18 | 24 | 32 |
| Filling Head No | 8 | 12 | 18 | 24 | 32 |
| Capping Head No | 3 | 4 | 6 | 8 | 10 |
|
Rated Capacity (500ml) |
3000BPH | 4000BPH | 5000-7000BPH | 8000-12000BPH | 12000-15000BPH |
| Overall Size |
1900*1420* 2000mm |
2200*1600* 2300mm |
2450*1900* 2300mm |
2750*1180* 2400mm |
4000*2300* 2300mm |
| Weight | 1.5T | 2.2T | 3.0T | 4.0T | 8.0T |
|
Power (KW) |
3.0kw | 3.5kw | 4.0kw | 4.8kw | 7.6kw |
| Rated Voltage | Customized | Customized | Customized | Customized | Customized |
Competitive Advantage:
1. One year warranty for the whole system
2. Free equipment installation and debugging
3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
4. Every 3 years, we can help to overhaul the machine free (Labor)
5. We can provide internship service and help you train the operator and mechanic
6. Free production technology and process configuration
7. We can help you to design the production line, workshop and provide turn-key project
Market Distribution:
| Market | Revenue(Previous Year) | Total Revenue (%) |
| Africa | confidential | 40% |
| Middle east | confidential | 15% |
| America | confidential | 5% |
| Euro | confidential | 4% |
| Middle Aisa | confidential | 3% |
| South-east Asia | confidential | 3% |
| Domestic | confidential | 30% |
