Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Product Details:
| Place of Origin: | China,JiangSu,Zhangjiagang |
| Brand Name: | FillPack |
| Certification: | CE. ISO9001 |
| Model Number: | TB-250 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set/pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Sea worthy package |
| Delivery Time: | 30 days after deposit receipt |
| Payment Terms: | TT / LC / |
| Supply Ability: | 1 set / month |
|
Detail Information |
|||
| Material: | Stainless Steel And Aluminium Alloy Parts | Production Capacity: | 15000BPM |
|---|---|---|---|
| Suitable Label: | PET Or PVC Label | Power: | 2Kw |
| Model: | TB-250 | Product Name: | Shrink Labeling Machine |
| Driven Type: | Electric | Weight: | 700Kg |
| High Light: | industrial labeling systems,sticker labeling machine |
||
Product Description
15000BPH double driving four blades installed shrink labeling machine with Panasonic driver
Shrink labeling machine---Technical parameters
|
Model |
TB-250 |
|
Input Power |
2KW |
|
Input Voltage |
3,380/220VAC |
|
Production Efficiency |
250(Bottle/min) |
|
Size of Host Machine |
L2700mm x W1100mm x H2150mm |
|
Applicable Diameter of Bottle Body |
28mm-120mm |
|
Applicable long of label |
30mm-250mm |
|
Applicable thickness of label |
0.03mm-0.13mm |
|
Applicable Internal Diameter of Paper Tube |
5”-10” |
Shrink labeling machine---Features
Production efficiency of equipment: 250 bottles/min
Double Contraction label feeding tray: automatically controlled by micro-computer
Automatic detection &positioning Swift and labor-saving for changing label
Absolutely precise cutting-off position
Shrink labeling machine---Electrical Appliance Configuration Specification
TB-250 is a kind high speed machine .But it adopts equivalent PLC,positioning module,servo motor and frequency converter. Besides,its touch screen is featured with a humanized operation.
Shrink labeling machine---Applicable Bottle Types
Various kinds of bottle types, for example; round bottle, square bottle, flat bottle, curved bottle and cup-oshaped, etc.
Shrink labeling machine---Description
---The shrink labeling machine is made of stainless steel and high quality of aluminum alloy, the struction is compact.
---No need to fasten feet bolts to the ground, it can be moved flexibly.
---Shrinking film volume label frame can be adjusted according to different volume label paper pipe from 5 to 10.
---Gear device can be adjusted conveniently without using tools, which makes it suitable for different bottles.
---The sleeving manner is forced sleeving which is convenient and reasonable.
---Measure system of cutting the volume label can achieve low errors.
---Knives can be changed easily and quickly with certain range.
---Bottle parting screw, location belt and conveying chian can be adjusted synchronously.
---The servo motor and high-delicacy photoelectricity from Japan make the cutting label precise
Shrink labeling machine---Technical parameter
| Model | TB-150 | TB-250 |
| Input power | 1.5Kw | 2.0Kw |
| Input voltage | D3,380/220VAC | D3,380/220VAC |
| Production Capacity | 150(Bottle/min) | 250(Bottle/min) |
| Size of Host Machine |
L2100mm x W850mm |
L2700mm x W1100mm |
| Applicable Diameter of Bottle Body | D28mm-125mm | D28mm-125mm |
| Applicable Length of Lable | 30mm-250mm | 30mm-250mm |
| Applicable Thickness of Label | 0.03mm-0.13mm | 0.03mm-0.13mm |
|
Applicable Internal |
(Free Adjustment) | (Free Adjustment) |
