Stainless Steel Pure water treatment equipment With Hydecanme Membrane
Product Details:
Place of Origin: | Zhangjiagang,Jiusu,China |
Brand Name: | Fillpack |
Certification: | CE,ISO |
Model Number: | RO-12 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 set/pcs |
---|---|
Price: | Negotiation |
Packaging Details: | Sea worthy packing |
Delivery Time: | 15-20 days |
Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
Supply Ability: | 20sets/month |
Detail Information |
|||
Model: | RO-12 | Production Capacity: | 12000LPH |
---|---|---|---|
Product Name: | Pure Water Treatment System | Core Part: | RO System |
Membrane Flow: | 12TPH | Membrane QTY: | 12 |
Housing Material: | SUS304 | Membrane Brand: | Hydecanme |
Membrane Model: | 8040 | Pumb: | NANFANG |
Filter Thickness: | 3mm | ||
Highlight: | water ro system,water purifying systems |
Product Description
Stainless Steel Pure water treatment equipment With Hydecanme Membrane
Introduction:
(1) Raw water Tank: The Raw Water tank store the raw water.The begain of the Pure Water Treatment System.
(2) Raw Water Pump: In order to the raw water through the pretreatment filter, we install a raw warter pumpto increase the water pressure.
(3) Silica sand filter: Silica sand filter can remove the suspended solid in water.
(4) Active Carbon filter-- mainly used for the removal and other organic gases and to clear up the taste of water
(5)Sodium ion exchanger -- exchange "ions" of calcium and magnesium with the most common and easiest method.
(6) Precision Filter: The pp cartridge installed on the precision filter, The pore of pp cartridge is 1-5um. so that the precision filter can remove the more small impurities to protect the reverse osmosis membrane.
(7) High Presure Pump: To increase the water pressure, let the water through reverse osmosis membrane.
(8) Reverse Osmosis Membrane: THE Reverse Osmosis Membrane is the most important part of the Pure Water Treatment System.Because the pore of the reverse osmosis membrane is 0.1nm. The pore of the bacteria is 0.5-1um and the pore of the virus is 0.018-0.022um. So the reverse osmosis membrane can remove the bacteria and virus.
(9) Oxygen Generator: Let the pure water become to oxygenated water.
(10) Ozone Generator: The ozone generator can keep the water fresh, and also can sterilize the water.
(11) Pure Water Tank: To store the pure wate
Feature:
1. Imported accessories account for over 90%]
2. High degree of automation operation
A. Automatic stopping in case of sufficient water under low pressure
B. Automatic stopping in case of sufficient water under high pressure
C. Protection of hydraulic resistance
D. Timed flushing of front filtering materials by automatic controller
E. Automatic flushing of reverse osmosis film by IC microcomputer
F. Automatic monitoring of water quality
3. Small landing area, low energy consumption, free of pollution, simple process, high water quality and easy operation
4. High removing rate, above 97% for dissolved salts, above 98% for organic substances and above 98% for colloids, bacteria and heat sources etc.
please kindly click the play button to watch the video
