Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

    • Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System
    • Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System
    • Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System
  • Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE & ISO & TUV & SGS
    Model Number: DCGFG24-24-8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 20000-50000USD
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Receiving Your Deposit Payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H): 3200*1900*2300 Mm Weight: 5000KG
    Power: 6KW Packaging Type: Crown Cap Glass Bottle
    Capacity: 6000-7000 Bph Control: PLC Control With Touch Screen


    Description of  DCGFG24-24-8 Crown Cap Glass Bottle Filling machine

    >>>Our machine have so many characteristics:

    ★1,  Structural hygiene: All parts in contact with beverages are made of high quality stainless steel, all liquid and gas pipes are polished inside and outside, and all seals in contact with beverages are made of nitrile rubber or silicone rubber for food, which meets the hygienic requirements.
    ★2,  Glass Bottle Making Machine Using programmable controller to realize fully automatic control from bottles entering to finishing packing, Glass Bottle Making Machine Using transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements, Adopting equal pressure filling principle and current spring valves in order to assure beverage quality, Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality.
    Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

    Teachnical parameters of DCGFG24-24-8
    Filling precision
    ≤+/-1mm(liquid level)
    Filling pressure
    ≤0.4MPa
    Glass bottle specification
    (Bottle diameter)50-100mm (Height)170-320mm
    Suitable cap shape
    Glass or other material screw cap
    Filling temperature
    0℃—5℃
    Cleaning pressure
    0.2-0.25MPa

    Our family of glass bottle carbonated filling machine
    There's always one suitable for you
    Model
    Rinsing filling capping heads
    Capacity(BPH)
    Power(kw)
    Weight(Kg)
    Dimension
    (mm)
    DCGFG12-12-4
    12/12/4
    1000-2000
    4.4
    2800

    DCGFG18-18-6
    18/18/6
    3000-4000
    5
    3800
    2360*1770*2700
    DCGFG24-24-8
    24/24/8
    6000-7000
    6
    5000
    3200*1900*2300
    DCGFG32-32-10
    32/32/10
    8000-10000
    8
    6000
    4300*2000*2300
    DCGFG40-40-12
    40/40/12
    10000-12000
    10
    9000
    4500*3500*2300

    If you need plastic bottle carbonated filling machines, please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.

    Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

    Carbonated Water Juice Wine PET Plastic Glass 3 In 1 Monobloc Bottling Machine / Equipment / Line / Plant / System

    FAQ

    Q: How to get an appropriate offer from YISUNDA Beverage?
    A: Please inform us:
    1, production capacity per hour/per day/per month ... ...
    2, filling liquid: water, juice, carbonated drink, beer or ... ...
    3, bottle type: plastic bottle, glass bottle, can or ... ...
    4, cap type: screw cap, crown cap, can lid or ... ...
    5, for water treatment, it's better offer us the raw water quality report ... ...
    6, PET Bottle Automatic Mineral Water Filling Machine

    Q: This is the first time I cooperate with your factory. How can I trust you about the machine quality?
    A: Before ordering the machine, we will make the offer very clear. For example, the material thickness, the brand etc. We can have the video call and I will show what we have in the factory; Also you can visit us to see the machine;

    Q: Can I run the machines in your factory if I buy the complete line in your factory?

    A: Sure, why not. We will have the line connected and tested in our factory before shipping even you didn't mention; We will make it working before arriving at your factory;

    Q: How can I install the machine and commissioning? Do you have the technician to my factory?
    A: We have the technician available to your factory for machine installation and commissioning; BUT client should be responsible for the round-way flight tickets, technicians' daily salary, local transportation, local hotel and eating.
