Semi Auto Mineral Water Stretch Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Product Details:
| Place of Origin: | China,JiangSu,Zhangjiagang |
| Brand Name: | FillPack |
| Certification: | CE. ISO9001 |
| Model Number: | FP-4000S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set/pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Sea worthy package |
| Delivery Time: | 35-40 days after deposit receipt |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 1 set / month |
|
Detail Information |
|||
| Bottle Volume: | 250ml-2L | Output: | 3500-4500bph |
|---|---|---|---|
| Cavitiy: | 4 Cavities | Dimension: | Customized |
| Power: | 24kw | Weight: | Customized, 6000kg |
| Condition: | New | Application: | PET Bottle |
| Automatic: | Yes | Blow Moulding Type: | Stretch Blow Moulding |
| Voltage: | 380V/220V 3 Phase 50HZ / 60HZ / Customized | Warranty: | 1 Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | ||
| High Light: | Bottle Injection Machine,Bottle Making Machine |
||
Product Description
Servo automatic 4 Cavity PET bottle blow molding machine suit
>>> Product Introduction:
FP-4000S servo automatic 4 Cavity PET bottle blow molding machine is suitable for blowing PET bottles of various shapes, volume from 250ml to 2000ml, wide application for blowing mineral water bottles, soda bottles,cola bottles.etc.
>>> Product Features:
●1. Advanced PLC control system with a user-friendly panel and time-control precision of PLC up to 0.01second
●2. Equipped with special designed air storage unit
●3. Using Infrared preform heater
●4. Independent Temperature Control for different heating lamp to get ideal preform heating results
●5. Heating lamps are adjustable in directions to suit various preforms.
>>> Technical Paramters:
|
Molding
|
Mold thickness
|
mm
|
240mm
|
|
Mold
|
mm
|
500*500mm
|
|
|
Number of Cavity
|
Cavities
|
4
|
|
|
|
Max.container volume
|
Itr
|
2
|
|
Neck.container range
|
mm
|
15mm-38mm
|
|
|
container diameter
|
mm
|
20mm-100mm
|
|
|
container height
|
mm
|
50mm-350mm
|
|
|
Theoretical output
|
bph
|
3500-4500
|
|
|
|
Power
|
v
|
380v 3Phase /220v 3Phase 50/60HZ
|
|
Really use power
|
kw
|
14kw
|
|
|
Rated Power
|
kw
|
49kw
|
|
|
Items
|
Components
|
Model
|
|
1
|
Blow Moulding Machine
|
FP-4000S
|
|
2
|
Preform Unscramble
|
FP-4000S
|
|
3
|
HP Air Compressor
|
2.0M3/min 30kg
|
|
4
|
LP Air Compressor
|
1.6M3/min 10kg
|
|
5
|
Air Dryer
|
2.0M3/min 30kg
|
|
6
|
Air Filters
|
2.0M3/min 30kg
|
|
7
|
Air Tank
|
0.6M3/min 30kg
|
|
8
|
Mould Chiller
|
3HP
|
|
9
|
Blow Mould
|
250-2000ml
|
|
10
|
PLC
|
Delta / Taiwan
|
