Pure Drinking PET Bottle Water 3 In 1 Monoblock Producing Equipment / Plant / Machine / System / Line
Product Details:
| Place of Origin: | Zhangjiagang, China |
| Brand Name: | FillPack |
| Certification: | CE / ISO9001 - 2008 |
| Model Number: | CGF32-32-10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 20000-40000USD |
| Packaging Details: | Wooden Case Package |
| Delivery Time: | 30 Working Days After Deposit |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 15 Sets Per Months |
|
Detail Information |
|||
| Weight: | 5500kg | Capacity: | 12000 Bph |
|---|---|---|---|
| Fuction: | Washing Filling Capping | Suitable Bottle Size: | 0.3-2L PET Bottle |
| Automation: | Automatic | Application: | PET Bottle Water |
| Dimension(L*W*H): | 3350*2680*2400 Mm | Voltage: | 220V/380V |
| High Light: | liquid filler equipment,water bottling equipment |
||
Product Description
Features of CGF 32-32-10 High speed automatic bottle water filling machine:
1. The whole machine adopts card bottle hanging running state design, so that the bottle under high-speed operation stable and reliable. Change a few fittings, Can be quickly and easily implement different bottle production need.
2. Using a new generation of tilting bottles clamp, stainless steel clamps and the bottle thread above part does not contact, bottle clamp with shower, to wash the bottle of any part of the wall.
3. Using advanced micro gravity type negative pressure filling principle, filling fast, stable and accurate. Silos is fully enclosed structure, there is the function of temperature control and automatic reflow, and provide the CIP cleaning interface.
4. This machine satisfies the requirement :of below 95 degrees Celsius hot filling technology, before-capping, equipped with bottle R.O. water flushing device, To ensure that the bottle no moldy phenomenon.
5. Using magnetic torque type screw cap, Pincer-like device tight and reliable and does not hurt cover.
Other machins in the line:
1. Automatic Bottle Blowing Machine
2. Automatic water Filling Machine
3. Sleeve Labeling machine
4. Heat Shrinking Machine
5. High Speed Packing Machine
|
Parameter
|
|
| Model | CGF32-32-10 |
| Capacity(B/H) | 15000 |
| Bottle size | Neck :φ50-100mm:Height:150-320mm |
| Water pressure | 0.18-0.25Mpa |
| Water consumption(kg/h) | 1000 |
| Washing station | 18 |
| Loading-Dripping-discharge station | 2-2-2 |
| Filling precision | <+1MM |
| Air pressure | 0.5Mpa |
| Air consumption (m³/min) | 0.3 |
| Power(kw) | 7 |
| Weight(kg) | 4000 |
| Dimension(L*W*H)(mm) | 3350*2680*2400 mm |
|
Electrical apparatus
|
||
| Transducer | Simens-Germany | |
| Touch screen | Simens-Germany | |
| PLC | Simens-Germany | |
| Stabilized voltage supply | MingWei-TaiWan | |
| Contactor | Schnider-French | |
| Approach switch | Schnider-French | |
| Air switch | Schnider-French | |
|
Optional RO water treatment machines in the water filling line
|
||||||
|
Model
|
Capacity(liter per hour)
|
|||||
|
RO-1000
|
1000LPH
|
|||||
|
RO-3000
|
3000LPH
|
|||||
|
RO-5000
|
5000LPH
|
|||||
|
RO-6000
|
6000LPH
|
|||||
|
RO-10000
|
10000LPH
|
|||||
|
Optional Washing-filling-capping machines in the filling line(3-in-1 and Linear type)
|
||||||
|
3in1(0-2L bottle)
|
Capacity(bottle per hour)
|
3in1(3-10L bottle)
|
Capacity
|
Linear type(3-10L bottle)
|
Capacity
|
|
|
CGF8-8-3
|
2000-3000BPH
|
CGF8-8-3B
|
0-1000
|
CGF4-4-1
|
500BPH
|
|
|
CGF12-12-4
|
3000-4000BPH
|
CGF12-12-4B
|
0-1500
|
CGF6-6-1
|
750BPH
|
|
|
CGF18-18-6
|
6000-7000BPH
|
CGF18-18-6B
|
0-2500
|
CGF8-8-1
|
1000BPH
|
|
|
CGF24-24-8
|
11000-12000BPH
|
CGF24-24-8B
|
0-3500
|
CGF10-10-1
|
1500BPH
|
|
|
CGF32-32-10
|
14000-15000BPH
|
CGF32-32-10B
|
0-5000
|
CGF12-12-1
|
2000BPH
|
|
|
CGF40-40-10
|
19000-20000BPH
|
|
|
|
|
|
|
CGF50-50-12
|
23000-24000BPH
|
|
|
|
|
|
|
|
||||||
|
More capacities if you need, we can also customize that for you. please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.
|
||||||
