3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine

3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine

    • 3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine
    • 3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine
    • 3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine
    • 3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine
  • 3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine

    Product Details:

    Place of Origin: Mainland, China
    Brand Name: FillPack
    Certification: CE. ISO
    Model Number: YFZX
    Automation: PLC contol
    Application: Paper pallet forming, packing and shrinking

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Sea worthy package
    Delivery Time: 45 days after deposit receipt
    Payment Terms: TT/LC/Wertern union
    Supply Ability: 1 set/sets/month
    Contact Now
    Detailed Product Description


    3 in 1 Carton Bottle Packing Machine , Shrink Wrapping Machine



    Quick details:
    1, Automatic PLC control
    2, High effiency
    3, Paper pallet forming, packing, shrinking machine


    Description

    This machine consists of cans inlet transmission parts, tank group parts, carton storage transmission parts, carton forming encapsulation parts, pneumatic parts and electric control parts.


    Characteristics:

    1. Specially design for carton packing for beer, beverage, bottled Water, medicament, food ect bottle production line, carton wrapping saves 1/5 cost than traditional packing type.
    2. Machine adopt convergence system and touch screen to control every function of operation, detecting error and display automatically. Convenient for maintenance and efficient.
    3. Well- known brand Servo motor and self lubricate lower abrasion chain. Working stably and efficient.
    4. Adopt known hot melt equipment, easy to operation, durable. Packaingeffect is artistic and easy for store and transportation.
    5. Liner feedind bottles and feeding cardboard system, advanced electirc collocation and technology. Configuration easy for operation.


    Parameter


    Model YFZX20 YFZX35 YFZX45 YFZX60
    Molding carton dimension 550<L+W+H<1000 550<L+W+H<1000 550<L+W+H<1000 550<L+W+H<1000
    Capacity 20cartons/min 35cartons/min 45cartons/min 60cartons/min
    Power supply capacity 380V,50Hz/13KW three phase 380V,50Hz/13KW three phase 380V,50Hz/16KW three phase 380V,50Hz/22KW three phase
    Hot-melt adhesive solidify time 1.5 ~2S 1.5 ~2S 1.5 ~2S 1.5 ~2S
    Working air pressure 0.6~0.8Mpa 0.6~0.8Mpa 0.6~0.8Mpa 0.6~0.8Mpa
    Bottle height scope 110 ~340(mm) 110 ~340(mm) 110 ~340(mm) 110 ~340(mm)
    Bottle diameter scope C 50 ~180(mm) C 50 ~180(mm) C 50 ~180(mm) C 50 ~180(mm)
    Machine weight 4500kg 5000kg 7000kg 11000kg
    Dimensions 8870L×3000W×1820H(mm) 8870L*3000W*1820H(mm)

    12380L×1960W
    ×1906H(mm)

    12380L×3820W
    ×2628H(mm)



    Competitive Advantage:

    1. One year warranty for the whole system
    2. Free equipment installation and debugging
    3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price
    4. Every 3 years, we can help to overhaul the machine free (Labor)
    5. We can provide internship service and help you train the operator and mechanic
    6. Free production technology and process configuration
    7. We can help you to design the production line, workshop and provide turn-key project
