Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH

Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH

    • Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH
    • Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH
    • Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH
    • Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH
  • Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH

    Product Details:

    Place of Origin: Zhangjiagang, China
    Brand Name: FillPack
    Certification: CE / ISO9001 - 2008
    Model Number: DCGF
    Condition: New
    Application: PET bottle water
    Automation: Automatic
    Suitable Bottle Size: 0.3-2L PET Bottle
    Fuction: washing filling capping monoblock
    Capacity: 3000-12000BPH
    Warranty: 1 Year for Spare Parts
    Service: Technician avaliable overseas

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Deposit
    Payment Terms: TT & L/C
    Supply Ability: 20 Sets Per Months
    Contact Now
    Detailed Product Description



    Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH





    Quick Detail:



    Machine structure: 3 in 1 washing filling capping machine

    Suitable Bottle: PET bottle

    Suitable cap: Plastic screw cap

    Suitable volume: 0.3-2L

    Suitable liquid: gas containing water
    Capacity: 15000bph
    Advantage: USA - Germany technology





    Description:



    1. The Small Bottle Automatic Water Filling Machine Monoblock is always short called Monoblock, usually it is used for small bottles which range is from 0.25L to 2L.

    2. The Small Bottle Automatic Water Filling Machine Monoblock is composed by rotary washer, normal pressure filler, screw type capper and conveying system.

    3. The Small Bottle Automatic Water Filling Machine Monoblock is using bottle neck holding technology for transfering system, that means bottles are held with star wheel and side plate at neck ring when transfering from washer to capper. It is easy for different volume bottles change.

    4. The speed of Small Bottle Automatic Water Filling Machine Monoblock is higher than traditional linear type machine.

    5. It is used for filling all kinds of non gas water, such as still water, mineral water, flavored water, spring water, oxygen water, hydrogen water.

    6. The usual production capacity is in 1000-24000bph, 0.2-2L PET bottle is available.









    Specifications:



    Model(DCGF) 12-12-5 18-18-6 24-24-8 32-32-8 40-40-10 50-50-12
    Number of washing,filling,capping heads 12-12-5 18-18-6 24-24-8 32-32-8 40-40-10 50-50-12
    Suited bottle specification (mm) Φ=50-100 H=170 330-1500ML Φ50-Φ110 H=160-340
    Production capacity(350ML)
    b/h
    2000-
    4000
    4000-
    6000
    8000-
    10000
    10000-12500 12500
    -15000
    16000
    -20000
    Washing pressure
    (MPa)
    0.2-0.25 0.2-0.25
    Filling pressure
    (MPa)
    0.15-0.35 0.15-0.35 0.15-0.35 0.2-0.4 0.2-0.4 0.2-0.4
    Motor power 1.5+0.55
    +0.12
    2.2+0.55
    +0.18
    3+0.55
    +0.18
    5.5+0.55
    +0.18
    7.5 11
    Overall dimensions
    (L×W×H)
    mm
    2300×1600
    ×2500
    2600×1920
    ×2550
    3100×2200
    ×2800
    3850×3000
    ×2850
    4850×3800
    ×2750
    5750×3550
    ×2750
    Weight kg 2800 3650 4800 6800 8650 10500





    Competitive Advantage:



    1. One year warranty for the whole system

    2. Free equipment installation and debugging

    3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

    4. Every 3 years, we can help to overhaul the machine free (Labor)

    5. We can provide internship service and help you train the operator and mechanic

    6. Free production technology and process configuration

    7. We can help you to design the production line, workshop and provide turn-key project



    Soft Drink Bottle Filling Machine Automatic Capping Equipment 15000BPH
