10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity

10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity

    • 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    • 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    • 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    • 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
  • 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity

    Product Details:

    Place of Origin: ZhangJiaGang,JiangSu,China
    Brand Name: FILL PACK
    Certification: CE. ISO9001
    Model Number: FP-500ll

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set/pcs
    Price: USD $14,500-15,500/Set
    Packaging Details: the oil bottle blowing machine is packed by wooden case.
    Delivery Time: within 30 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 10Set/Sets per month
    Contact Now
    Detailed Product Description
    Cavity: 2 Cavities Output: 1000bph
    Heating Power: 16kw Carrige: 96pcs
    Volume: 3-10L Bottle Mouth: 28mm
    Key Word: Oil Bottle Blowing Machine Shaps: All Kind Ships
    Application: PET Plastic Neck: 10-120mm
    Warranty: 1 Year Automatic: No
    Voltage: 220V/380V Model: FP-500ll
    Machine Type: Pet Bottle Blowing Machine 500 Bph After-sales Service Provided: Engineers Available To Service Machinery Overseas





    10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity


    Product Description
    Specification:
    FP-500ll Oil Bottle Blowing Machine is especially used to produce 10L bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
    ● Perfect function with economic investment.
    ● Small size and compact construction with no space waste.
    ● Easy to operate and maintain ,operation by one person .
    ● Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
    ● We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer’s requirements.

    Technique Parameter of Oil Bottle Blowing Machine:

    Main parameter:
    Model DY-500ll
      Container Product material PET
    Volume 0-5L
    output 1000PCS/H
    Preform length 15mm-320mm
    Preform inner diameter φ5mm-200mm
      Moulding

    Max.mould plate Dimenstion

    (L x W)

    520x350mm
    Max.mould thickness 180mm
    Clamping force 480KN
    Mould opening stroke 420mm
      Machine size and weight Main machine (L x W x H) 1850*610*1700mm
    Main machine weight 800Kg
    Heater (L x W x H) 1800*610*1400mm
    Heater weight 300Kg
    Power 40kw

    Detailed Images
                     HP air compressor                                                                                                                                   Air Filter:
    10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity

    Refrigeration Air Dryer Unit 2.0M3/min 3.0Mpa
    Flow capacity Nm3/min 2.0
    W.P Mpa 3.0
    Inlet Temp. ≤80
    Dew point 23
    Ambient Temp. ≤38
    Power supply V/HZ 220/50
    Compressor power Kw 0.75
    Cold Medium mm 1050×650×1100
    Weight Kg 120

     Packing & Delivery
    1. the Oil Bottle Blowing Machine is packed by wooden case.
    2. The delivery date of Oil Bottle Blowing Machine is within 30 days after payment.

    10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity 10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity
    Our Service

    1.installation&commissioning

    After the equipment arrived at the customer's site. the customer is responsible for unpacking and arranging the equipment according to the placement drawing;Our technician will do equipment set up and commissioning,buyer should offer necessary help if needed



    2.Training

    We are responsible for offering the technical training to user.Through training,users' technical staff can grasp and the skill of operation and maintenance proficiently.The buyer also can send staff to our company for learning.



    3.Quality assurance

    The warranty period is 12 months after acceptance chech of the production line.if there is any different between the furnished equipment in the customer's factory and the equipment concerned in the contract.




      10 L Semi Automatic Oil Bottle Blowing Machine For Plastic Bottle With 2 Cavity

    please kindly click the play button to watch the video
