Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System

Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System

    • Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
    • Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
    • Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
    • Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
  • Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE. ISO9001
    Model Number: FP-6000S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set/pcs
    Price: Negotiation
    Packaging Details: Sea worthy package
    Delivery Time: 35-40 days after deposit receipt
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 1 set / month
    Contact Now
    Detailed Product Description
    Bottle Volume: 250-750ml Output: 5200-7500 Bph
    Cavitiy: 6 Cavities Dimension: Customized
    Power: 72kw Weight: 4550Kg
    Condition: New Application: PET Bottle
    Automatic: Yes Blow Moulding Type: Stretch Blow Moulding
    Voltage: 380V/220V 3 Phase 50HZ / 60HZ / Customized Warranty: 1 Year
    After-sales Service Provided: Engineers Available To Service Machinery Overseas

    Automatic Linear servo 6 Cavity PET bottle blow molding machine suit

    >>> Product Introduction:
    FP-6000S Full automatic blow molding machine is suitable for producing PETplastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

    >>> Product Features:

    1. Two ways of operating: automatic and manual
    2. Safe, reliable and unique design of the position of valve to make the pneumatic diagram in the machine easier to understand.
    3. Low cost, high efficiency, easy operation and maintenance, etc, profited from the fully automatic technological process.
    4. Ideal cooling system make the finished bottles without any flaws.
    5. Easy for you to install, test and start up
    6. Low rejection rate: less than 0.2%.

    Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
    >>>Flow and Auxiliary machines:
    HP Air Compressor → Air Tank → Air Filter →Air Dryer → Air Filter → Chiller → LP Air Compressor →Automatic Bottle Blowing Machine

    1. Auxiliary Machine To operate this PET blowing machine, it also need some auxiliary machines. such as air compressor, air filter, air dryer, chiller and so on. we will equip the auxiliary machine according to your need.
    2. Bottle Preform If you need, we can also help you find the bottle preform in china.


    >>>Technical Paramters:



    Molding
    Max. stretching distance
    mm
    800*350mm
    mold thickness
    mm
    180mm
    Number of Cavity
    Cavities
    6

    Container
    bottle body diameter
    mm
    30mm-110 mm
    bottle height
    mm
    50mm-320 mm
    bottle neck diameter
    mm
    18mm-38  mm
    Theoretical output
    bph
    5200-7500

    Electrical system
    power voltage
    v
    3Phase 380v /50HZ
    installed power / actual power
    kw
    72kw/56kw
    Servo system
    kw
    Taiwan Delta
    Items
    Name of Machines
    Model
    1
    Blow Moulding Machine
    3700*2050*2200mm/4000kg
    2
    Preform Unscramble
    2000*1350*2550mm/550kg
    3
    HP Air Compressor
    4.8 m3/ min 30Kg
    4
    LP Air Compressor
    2.0 m3/min 12Kg
    5
    HP/LP Air Dryer
    5.0 m3/ min 30Kg   2.0 m3/min 10Kg
    6
    HP/LP Air Filters
    5.0 m3/ min 30Kg   2.0 m3/min 10Kg
    7
    HP/LP Air Tank
    2.0 m3/ min 30Kg   1.0 m3/min 10Kg
    8
    Mould Chiller
    5HP
    9
    Blow Mould
    250-750ml
    10
    PLC
    Delta / Taiwan
    11
    Touch Screen
    Delta / Taiwan
    Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
    Automatic Energy Juice Oil Beverage Pet / Plastic Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
