Bucket / Barrel / Gallon Bottle Water Production Equipment / Plant / Machine / System / Line
Product Details:
| Place of Origin: | ZhangJiaGang JiangSu China |
| Brand Name: | FILL PACK |
| Certification: | CE, ISO9001 |
| Model Number: | QGF-450 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD $40000-$60000/set |
| Packaging Details: | Blanket cloth or wooden case |
| Delivery Time: | 15-20working days |
| Payment Terms: | L/C, D/A, D/P, T/T, , MoneyGram |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Capacity: | 450BPH | Gas Consumption: | 0.37m3/min |
|---|---|---|---|
| Key Selling Points: | Easy To Operate | Dimension(L*W*H): | 4500*1600*2400mm |
| Highlight: | 450BPH Bottle Water Production Equipment,0.37m3/min Bottle Water Production Equipment,1.5KW Bottle Water Production Equipment |
||
Product Description
Description of our 450BPH 5 gallon filling line
How to find a suitable 5 Gallon filling line?
1. Do you need additional spare parts for vulnerable parts?
2. Are there any brand or other requirements for the electrical parts of the machine?
3. Does the gallon filler(more than 300 bottles) require special matching machines, such as bottle bag packing machine or gallon palletizer?
|
Stainless Steel 18.9L Volume Gallon bottling line/machine/device 450BPH three station
|
||
|
Items
|
Name of machine
|
Model
|
|
1
|
Automatic De-capper
|
CR-1
|
|
2
|
Brush Internal-External Bottle Washer
|
NWS-1
|
|
3
|
Washer/Filler/Capper with auto bottle loading
|
WFC-450BPH
|
|
4
|
Heat Shrinking Machine
|
ZSM-1
|
|
5
|
Checking Light
|
CL-1
|
|
6
|
Conveyor Belt with Motor
|
11 meters
|
Automatic De-capper:
|
Parameters
|
|
|
Dimension
|
650*800*1600mm
|
|
Weight
|
100kg
|
Washer/Filler/Capper with auto bottle loading:
The Gallon bottling line set up do not need plug floor screw,after case taking off,set the machine on the flat floor,and then adjust stand height and adjust all stand pressure to be average. After the machine is set up well, get in through water pipe, drain pipe and power , air power.
|
Parameters
|
|
|
Cylinder
|
Air tech-Taiwan
|
|
Magnetic valve
|
Air tech-Taiwan
|
|
Rising pump-filling pump
|
Nanfang
|
|
Motor
|
TWT Taiwan
|
|
PLC
|
Mitsubishi Japanse
|
|
Power
|
1.5KW
|
|
Dimension
|
4500*1800*1800mm
|
|
Weight
|
800kg
|
Packing & Delivery:
1. the Gallon bottling line is packed by wooden case.
2. The delivery date of Gallon bottling lineis within 30 days after payment.
ZhangJiaGang City FILL-PACK Machinery Co.,Ltd. is loacated in Zhangjiagang city which is famous for beverage machinery producer collection. Intergrated the industry advantange and its own development in R&D, production, sales, after sales service, FILL-PACK is ready to serve more and more customers with our full range products and satified service.
FILL-PACK product is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.
