High Capacity SUS304 Bottle Packing Machine Sterilizer 4 Temperature Zones

High Capacity SUS304 Bottle Packing Machine Sterilizer 4 Temperature Zones

Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FillPack
Certification: CE. ISO9001
Model Number: PL

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Sea worthy package
Delivery Time: 25 days after deposit receipt
Payment Terms: TT / LC /
Supply Ability: 1 set / month
Get Best Price Contact Now

Detail Information

Condition: New Process Type: Bottle Cooling And Warming Machine
Voltage: 380V 3phase 50HZ / Customize Bottle Type: Various Bottles
Material: SUS304 / SUS316 Pump: Nanfang Pump
High Light:

Sterilizer System


Shrink Packing Machine

Product Description

High Capacity SUS304 Bottled Juice Cooling Sterilizer 4 Temperature Zones



Quick Detail:


1, Processing type: Bottle cooling and warming machine

2, Bottle type: Various bottes

3, Working temperature: Room temperature

4, Recycling tank for saving energy

5, Heating manner: steam heating and electric heating





The bottle cooling sterilizer is applied to PET bottle tea or juice hot filling production line and PET bottle carbonated drink filling production line. For hot filling, it can put down the temperature of hot filling drink to 36-40. For low -temperature filling, it can get up the temperature to 36-40 to eliminating the condensed water on the external wall of PET bottes, to keeping bottles dry and clean. So convenient to following-up labeling and packing process.





1. The tunnel spraying cleaning is continuous transmission;

2. Heat by coiled pipe hot vapor;

3. Several temperature zones will be designed basing on production capacity, processing requirement etc;

4, The top plate can be removed for easy maintainence;

5, Two heating manners: steam heating & electric heating;

6, There is insulation layer outside of the fram for better cooling and warming;





Production capacity (BPH) 3000-5000 6000-9000 10000-15000 24000-36000
Heating temperature (℃) 37-45 37-45 37-45 37-45
Cooling time (min) 12-15 12-15 12-15 12-15
Linear conveyoring speed (m/min) 100-550 100-550 100-550 100-550
Width of mesh conveyor (mm) 1.22 1.22 1.22 1.22
Vaport pressure (Mpa) < 0.4 < 0.4 < 0.4 < 0.4
Vapor consumption (kg/h) 80 120 240 280
Water circulation volum (m3/h) 6 9 15 28
Installed power (kw) 6 7.55 8.6 18
Dimension (L*W*H) 620*1500*1700 1580*1500*1700 1580*1800*1700 22000*800*1700
Weight (KG) 2500 3200 4300 5600



Competitive Advantage:


1. One year warranty for the whole system

2. Free equipment installation and debugging

3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

4. Every 3 years, we can help to overhaul the machine free (Labor)

5. We can provide internship service and help you train the operator and mechanic

6. Free production technology and process configuration

7. We can help you to design the production line, workshop and provide turn-key project
