Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer

Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer

    • Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer
    • Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer
    • Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer
    • Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer
  • Hot Filling Line Bottle Packing Machine Sterilizer Steam Heating Insulation Layer

    Product Details:

    Place of Origin: China,JiangSu,Zhangjiagang
    Brand Name: FillPack
    Certification: CE. ISO9001
    Model Number: PL

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set/pcs
    Price: Negotiation
    Packaging Details: Sea worthy package
    Delivery Time: 25 days after deposit receipt
    Payment Terms: TT / LC / Western union
    Supply Ability: 1 set / month
    Contact Now
    Detailed Product Description
    Condition: New Process Type: Bottle Cooling And Warming Machine
    Voltage: 380V 3phase 50HZ / Customize Bottle Type: Various Bottles
    Temperature Zone: 4 Sections Power: 6kw

    Hot Filling Line Bottled Juice Cooling Sterilizer Steam Heating Insulation Layer





    Quick Detail:



    1, Processing type: Bottle cooling and warming machine

    2, Bottle type: Various bottes

    3, Working temperature: Room temperature

    4, Recycling tank for saving energy

    5, Heating manner: steam heating and electric heating

    6, Temperature zone: 4 sections / customize





    Description:



    The bottle cooling sterilizer is applied to PET bottle tea or juice hot filling production line and PET bottle carbonated drink filling production line. For hot filling, it can put down the temperature of hot filling drink to 36-40. For low -temperature filling, it can get up the temperature to 36-40 to eliminating the condensed water on the external wall of PET bottes, to keeping bottles dry and clean. So convenient to following-up labeling and packing process.





    Features:



    1. Several temperature zones will be designed basing on production capacity, processing requirement etc;

    2, All the pumps are Nanfang pump;

    3, The top plate can be removed for easy maintainence;

    4, There is recycling tank in the bottom for saving energy;

    5, Two heating manners: steam heating & electric heating;

    6, Suitable for juice / tea filling line, hot filling line, beer filling line, soft drink filling line etc;





    Specifications:



    Production capacity (BPH) 3000-5000 6000-9000 10000-15000 24000-36000
    Heating temperature (℃) 37-45 37-45 37-45 37-45
    Cooling time (min) 12-15 12-15 12-15 12-15
    Linear conveyoring speed (m/min) 100-550 100-550 100-550 100-550
    Width of mesh conveyor (mm) 1.22 1.22 1.22 1.22
    Vaport pressure (Mpa) < 0.4 < 0.4 < 0.4 < 0.4
    Vapor consumption (kg/h) 80 120 240 280
    Water circulation volum (m3/h) 6 9 15 28
    Installed power (kw) 6 7.55 8.6 18
    Dimension (L*W*H) 620*1500*1700 1580*1500*1700 1580*1800*1700 22000*800*1700
    Weight (KG) 2500 3200 4300 5600





    Competitive Advantage:



    1. One year warranty for the whole system

    2. Free equipment installation and debugging

    3. After one year, we can help you to maintain the machine and the accessories are provided only one the cost price

    4. Every 3 years, we can help to overhaul the machine free (Labor)

    5. We can provide internship service and help you train the operator and mechanic

    6. Free production technology and process configuration

    7. We can help you to design the production line, workshop and provide turn-key project
