Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FILLPACK
Certification: CE,ISO
Model Number: QGF-900

Payment & Shipping Terms:

Minimum Order Quantity: 1 set/pcs
Price: Negotiation
Packaging Details: Blanket cloth or wooden case package as machine need
Delivery Time: 25 days
Payment Terms: L/C, T/T,
Supply Ability: 30 sets/month
Get Best Price Contact Now

Detail Information

Processing Type: 5 Gallon Bottle Filling Material: Stainless Steel
Capacity: 900BPH Sutabel Bottle: 5 Gallon Bottle
Power: 9.75Kw Filling Heads: 6
High Light:

automatic filling machine


bottle filler machine

Product Description

                  Automatic 900BPH 6 lines type gallon filling machine with Nanfang pump



Gallon filling machine---Detailed parameter




Capacity 900 barrels / hour
Filling head 6
Material SUS304
Suitable bottle 5 gallon
Motor power 9.75 KW
Dimension  5000*4000*1600
Weight 3500kg



Gallon filling machine----Product introduction


     Gallon filling machine specially produces gallons bottled drinking water, whose types (b/h) are: 100 type, 200 type, 300 type, 450 type, 600 type, 900 type.

     Gallon filling machine integrates bottle washer, filler and sealer into one unit, in order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer. Washing solution can bo used circularly. The sealer can seal bottle caps automatically carry out bottle feeding, washing, sterilizing, filling, capping, counting and products discharging.

    The Bottle Washer Filler and Sealer is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.



Gallon filling machine----More details


model production capacity power  overall dimensions
QGF---120 120B/H 2.8kw 2500*900*1445
QGF---200 200B/H 3.3kw 3000*1350*1560
QGF---300 300B/H 4.5kw 3500*1400*1560
QGF---600 600B/H 5.7kw


QGF---900 900B/H 9.75kw






A. The device employs key components of electrical appliances and metal materials manufactured

by name brand factories from home and abroad.

B.  It is not only with the advanced technology, high automatization, easy operation and reliable

performances as the genuine device from abroad, but also features with small size, small weight

and beautiful appearance,

C. Anti-corrodibility, thorough disinfection, effective anti-air pollution and high quality.

D. Available for the production of 5 & 3 gallons bottle filling, Capacity: 900B/H

E.  Apply to the food & drink industry, medical industry and chemical industry widely
