3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp

3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp

    • 3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp
    • 3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp
    • 3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp
    • 3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp
  • 3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: FILLPACK
    Certification: CE,ISO
    Model Number: CGF12-12-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: USD 19800/Set
    Packaging Details: Wooden case pacakge or Blanket cloth package
    Delivery Time: 25-30 days
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 20 Sets/Month
    Contact Now
    Detailed Product Description
    Type: Filling Machine Application: Beverage
    Packaging Type: PET Bottle- 45 Size Screw Cap, 2-5L Packaging Material: Plastic
    Automatic Grade: Automatic Filling Capacity: 1200BPH
    Structure: 3 In 1 Monoblock Conveyor: With 2m Feeding Chain Conveyor And 4m Outlet Conveyor
    Feature: With Belt Lubrication Function Power: 3.5kw
    Driven Type: Electric



    3 in 1 big bottle filling machine for plastic bottle - 45mm screw cap


    Quick Detail:


    Machine typeBottle water filling machine
    Filling capacity1200BP
    Filling materialDrinking water or mineral water
    Suitable bottlePET bottle from 2-5L
    Automatic typeFull automatic with PLC touch screen
    Structure3 in 1 monoblock
    Electrical control With independent cabinet



    Main Description:

    The 5L filler is used for filling drinking water, pure water, mineral water in 5L plastic bottle with screw cap for market selling.



    Main Technician Datas:


    ModelCGF12-12-5
    Capacity1200BPH (5L)
    Washing head12
    Filling head12
    Capping head5
    Main materialSUS304
    Applicable bottlePET bottle-screw cap, 2-5L
    Filling pressureNormal pressure
    Washing materialClear water, pure water
    Water washing pressure0.25Mpa
    Filter membrane shellFRP membrane shell
    Pump power3.5kw
    Size3100*2300*1970mm
    Weight3200kg




    Features:

    --Set with 2m inlet bottle conveyor and 4m outlet chain conveyor, the conveyor width is adjustable as your bottle size.
    --With bottle feeding conveyor, washing part, filling part, capping part, cap sorting, cap loading function, cap washing system, with belt lubrication function, sperately electric control cabinet.
    --Full automatic with PLC touch screen control system, speed is stepless adjustable.


    --Monoblock with bottle washing, filling, capping parts together, 12 rotary washing heads,12 rotary filling heads, 5 rotary capping heads, more convenient to use.
    --Main adopts high quality of stainless steel 304 material, meet with the food grade.
    --Adopts the normal filling pressure, with stable filling function and high filling precision.


    -- Independently electric control cabinet for easy control the every part of whole machine.
    -- With cap washing system to wash the cap with pure water or sterilized water, to guarantee the cap health, improve the water quality.
    --With 4m outlet chain conveyor and running speed motor.


    --With rotary 12 filling heads, 5 capping heads.
    --Normal filling pressure, high precision filling head.
    --Screwing capping head dual-purpose design; for flat cap and sport cap.
    --Capping part can take out the reverse cap and prevent the reverse cap passing is settled in the cap-falling guide.
    --Photoelectric switches are settled on cap-falling guide,stop when there is no cap on the guide.
     3.5kw Juice Filling Machine For Plastic Bottle 45mm Screw Capp
