500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line

500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line

    • 500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line
    • 500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line
    • 500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line
  • 500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line

    Product Details:

    Place of Origin: Zhangjiagang, China
    Brand Name: FillPack
    Certification: CE / ISO9001 - 2008
    Model Number: CGF50-50-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 20000-40000USD
    Packaging Details: Wooden Case Package
    Delivery Time: 30 Working Days After Deposit
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 15 Sets Per Months
    Contact Now
    Detailed Product Description
    Capacity: 3000BPH Suitable Bottle Size: 0.3-2L PET Bottle
    Automation: Automatic Bottle Volume: 200ml-2000ml
    Dimension(L*W*H): 2100*1750*2100mm Voltage: 380V 50Hz

    Decription of CGF50-50-12 Pure drinking water PET bottle 3 in 1 bottling line for 0-2L bottle

    >>>Characteristics:
    ★The 500ml water production machine is used in production of non-soda drink of mineral-pure water packed in polyester bottles. Washing, filling and capping are integrated in one machine.
    ★The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.

    ★1.Except the down framework, the transmission parts and some parts that must be made of special materials. Other spare parts are made of stainless steel 304.
    ★2.By adjusting the height of the rotary parts to adapt for different bottle height.

    ★1) Adopted Germanyanti-corrosion non-maintaining bearing that can reduce the pollution of filling to the environment.
    ★2) This filling system has an automatic temperature control system.

    This 500ml water production machine is the highest degree of accuracy of 3 in 1 machine, it is important for the machine to run stably and the product quality.
    A group of photoelectric switches are settled on cap-falling guide. The machine will stop when there is no cap on the guide.

    Parameters
    Model
    CGF50-50-12
    Capacity(B/H)
    24000
    Bottle size
    Neck :φ50-100mm:Height:150-320mm
    Water pressure
    0.18-0.25Mpa
    Water consumption(kg/h)
    1000
    Washing station
    18
    Loading-Dripping-discharge station
    2-2-2
    Filling precision
    <+1MM
    Air pressure
    0.5Mpa
    Air consumption (m³/min)
    0.3
    Power(kw)
    8
    Weight(kg)
    4000
    Dimension(L*W*H)(mm)
    4550*3500*2400 mm



    Electrical apparatus
    Transducer
    Simens-Germany
    Touch screen
    Simens-Germany
    PLC
    Simens-Germany
    Stabilized voltage supply
    MingWei-TaiWan
    Contactor
    Schnider-French
    Approach switch
    Schnider-French
    Air switch
    Schnider-French



    500ml / 1L / 2L PET Drinking Water 3 In 1 Monoblock Production Equipment / Plant / Machine / System / Line



    We have 3-in-1 washing-filling-capping machine for 0-2L bottle and 3-10L bottle.
    We also have linear type washing-filling-capping machine for 0-2L bottle and 3-10L bottle.
    The capacity of linear type is not faster than 3-in-1, and it's floor area is slightly larger, but the price is more cheaper than 3-in-1.
    Our Washing-filling-capping machines (3-in-1 and Linear type)
    3in1(0-2L bottle)
    Capacity(bottle per hour)
    3in1(3-10L bottle)
    Capacity
    Linear type
    Capacity
    CGF8-8-3
    2000-3000BPH
    CGF8-8-3B
    0-1000
    CGF4-4-1
    500BPH
    CGF12-12-4
    3000-4000BPH
    CGF12-12-4B
    0-1500
    CGF6-6-1
    750BPH
    CGF18-18-6
    6000-7000BPH
    CGF18-18-6B
    0-2500
    CGF8-8-1
    1000BPH
    CGF24-24-8
    11000-12000BPH
    CGF24-24-8B
    0-3500
    CGF10-10-1
    1500BPH
    CGF32-32-10
    14000-15000BPH
    CGF32-32-10B
    0-5000
    CGF12-12-1
    2000BPH
    CGF40-40-10
    19000-20000BPH




    CGF50-50-12
    23000-24000BPH





    More capacities if you need, we can also customize that for you. please check them on our website or contact the sales consultant directly. Please find the contact information at contact us.
