Air Purified Aspetic Water Filling Machine Solenoid Valve CE

Air Purified Aspetic Water Filling Machine Solenoid Valve CE

Product Details:

Place of Origin: China,JiangSu,Zhangjiagang
Brand Name: FillPack
Certification: CE & ISO
Model Number: CGF32-32-10
Control: PLC Control With Touch Screen
Processing: Japan & Germany
Capacity: 12000-15000BPH
Electrical Brand: Mitsubishi, OMRON, SIEMENS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 12000-40000USD
Packaging Details: Wooden Case Package for bottle filling machine
Delivery Time: 30 Working Days for bottle filling machine
Payment Terms: T/T, L/C, , MoneyGram
Supply Ability: 20 Sets Per Year
Get Best Price Contact Now

Detail Information

Processing Type: Bottle Filling Machine Material: Touch Parts SUS304/SUS316
Machine Structure: Monoblock Machine Filling Type: Normal Pressure Filling
Cap Style: Plastic Screw Cap Electrical Brand: Mitsubishi, OMRON, SIEMENS
Highlight:

water production line

,

water filler machine

Product Description



Air purified aspetic bottle filling machine solenoid valve 15000BPH


Quick Detail:


Processing type Bottle filling machine

Machine structure

Washing, filling, capping 3 in 1 unit

Filling type

Normal pressure filling machine

Bottle type

15000BPH plasic bottles

Cap type

Bio caps: plastic screw cap & sport cap



Short description:

The water bottle filling machine is one of the most pupular filling machine for filling water into plastic bottles with screw caps.

The water bottle filling machine is suitable for filling water, fresh juice etc.


Features:


Machine structure

1, Washing, filling, capping in one unit
2, More compact
3, Ring type water cylinder
4, Rotary type filling machine - No residual
5, Top covered by stainless steel 304
6, UV lamb inide for killing bacteria
7, Low labor

Filling type& speed

1, More precise
2, High capacity
3, Normal pressure filling machine

Material

1, Stainless steel 304
2, Contact parts: Stainless steel 316
3, Pipe & valve connection: food grade seamless pipe

Controlling system

1, PLC cntrol
2, Touch screen
3, Solenoid valve
4, Low labor



Datas:


Model

CGF8-8-3

CGF12-12-6

CGF18-18-6

CGF24-24-8

CGF32-32-10

Rinsing Head No

8

12

18

24

32

Filling Head No

8

12

18

24

32

Capping Head No

3

6

6

8

10

Rated
Capacity
(500ml)

2000BPH

4000BPH

7000-8000BPH

10000-15000BPH

15000-20000BPH

Overall Size

1900*1420*
2000mm

2200*1600*
2300mm

2450*1900*
2300mm

2750*1180*
2400mm

4000*2300*
2300mm

Weight

1.5T

2.2T

3.0T

4.0T

8.0T

Power
(KW)

3.0kw

3.5kw

4.0kw

4.8kw

7.6kw

Rated Voltage

Customized

Customized

Customized

Customized

Customized



Complete Flow Chart of bottle filling mahine

                                                                                                                      Ion Re-birth Device
                                                                                                                                         V
Raw Water Source > Booster Pump > Quartz Sand Filter > Active Carbon Filter > Water Softener>RO

Unit > UV Sterilizer > Pure Water Storage Tank < Ozone Machine


                                                                                                                           (Steam Generator)
                                                                                                                                           V
Bottle Blowing System >  Monoblock Water Filling Machine > Labeling machine > (Shrinking Tunnel)>Code

Printer > Shrink Wrapping Machine
